ASUS NUC 15 PRO+ MINI PC, U5-225H, DDR5(0/2), M.2(0/1), SILVER, 3YR RNUC15CRHU500004
AI-Enabled Mini PC Powered by Intel® Core™ Ultra processors (Series 2). Designed as the best compact choice for the AI-driven future. Powered by Intel® Core™ Ultra processors (Series 2), delivering up to 99 Platform TOPS and an 18% boost in performance gen-on-gen. Supports up to 96GB dual-channel DDR5-6400 memory for seamless multitasking and high-speed workloads. Features Intel® Arc™ Graphics for AI acceleration and stunning visual performance, with Intel® vPro® for enterprise-grade security and management. Includes PCIe Gen5 NVMe SSD and Gen4 expansion slots for ultra-fast storage and flexibility. Connects up to four 4K displays via dual HDMI 2.1 and Thunderbolt™ 4 with DisplayPort 2.1 and USB4 compatibility. Offers advanced connectivity with Intel® Wi-Fi 7, Bluetooth® 5.4, and multiple high-speed USB 3.2 Gen2 ports. Compact 0.48L design with tool-less chassis enables quick upgrades and effortless deployment. Built for reliability with MIL-STD-810H certification, efficient cooling, and eco-friendly packaging for sustainability.
| Form Factor | Kit |
| Operating System | No preinstalled OS Support: Windows 11 RedHat Enterprise Linux Ubuntu 24.04 LTS |
| CPU | Intel® Core™ Ultra 5 225H, cTDP 40W |
| Chipset | Integrated |
| Graphics | Intel® Graphics Intel® Arc™ GPU (Core Ultra) *Intel® Arc™ GPU requires using 2 x SO-DIMM |
| Memory | No memory included at shipment Max Capacity: 48GB DDR5-5600 SO-DIMM x 2 or 48GB DDR5-6400 CSO-DIMM x 2 No memory included at shipment Max Capacity: 48GB DDR5-5600 SO-DIMM x 2 or 48GB DDR5-6400 CSO- |
| Storage | No storage included at shipment Support: 128GB~8TB M.2 2280 NVMe™ PCIe® 5.0 x 4 SSD (Core Ultra Series CPU) or 128GB~8TB M.2 2280 NVMe™ PCIe® 4.0 x 4 SSD (Core Series CPU)+ 128GB~2TB M.2 2242 NVMe™ PCIe® 4.0 x 4 SSD |
| Wireless Data Network | Intel® Wi-Fi 7 BE202, Bluetooth 5.4 *Bluetooth® version may change with different OS version. Intel® Wi-Fi 7 BE201, Bluetooth 5.4 Intel® Wi-Fi 7 BE201,vPro®, Bluetooth 5.4 Intel® vPro® Technology (i7/i5 vPro SKUs only) |
| LAN | Intel® Ethernet Controller I226-V, 2.5G Intel® Ethernet Controller I226-LM, 2.5G *Intel® Ethernet Controller I226-LM included on vPro enabled systems |
| Front(Side) I/O Ports | 1 x USB 3.2 Gen2x2 Type-C 2 x USB 3.2 Gen2 Type-A 1 x Kensington Lock (Side) |
| Back I/O Ports | 2 x HDMI 2.1 TMDS Compatible (4K@60Hz) 2 x Thunderbolt™ 4 ports (incl. DP 2.1 and USB4) 1 x USB 3.2 Gen2 Type-A 1 x USB 2.0 Type-A 1 x RJ45 LAN 1 x DC-in |
| Power Supply | 19VDC, 4.74A, 90W Power Adapter (i3 CPU) 19VDC, 6.32A, 120W Power Adapter 19VDC, 6.32A, 120W Power Adapter (Core Ultra 5/7) |
| Dimensions (W x D x H) | 117mm x 112mm x 54mm |
| Weight | 600g |
| Accessories | AC Adapter+Power Cord* VESA Bracket and Screws Cable Clip Safety/Caution/Regulatory Insert Warranty Card *Power cord included is region specific, and some SKUs do not include the power cord Warranty Card Safety/Caution/Regulator |
