Eaton 9SX 6000VA/5400W On Line Tower Ups, 240V 9SX6KI-AU
SKU
446650
Brand
MPN
9SX6KI-AU
Warranty
Standard Manufacturer's Warranty
$9,334.00
Buy Now And Earn 9334 Reward Points!
Eaton Eaton 9SX 6000VA/5400W On Line Tower UPS, 240V is a supplier-matched product available from Spot IT.
Use this item for compatible business, office, and IT requirements. Manufacturer part number: PW86365.
Order online for Australia-wide delivery with local support.
Use this item for compatible business, office, and IT requirements. Manufacturer part number: PW86365.
Order online for Australia-wide delivery with local support.
| SKU | 9SX6KI-AU |
|---|---|
| Brand | Eaton |
| Color | Black (RAL 9005) |
| Model | 9SX6KI-AU |
| Bypass | Internal static bypass |
| Series | 9SX |
| Display | Multilingual graphical LCD |
| Altitude | <1000 m for nominal power; ~10% power degradation every additional 1000 m up to 3000 m |
| Category | Power and Rack Equipment |
| Topology | On-line double conversion (with PFC) |
| Warranty | 2 years (manufacturer stated) |
| Description | The Eaton 9SX 6000VA / 5400W on-line double-conversion tower UPS (model 9SX6KI-AU) delivers premium power protection for IT and network equipment. Designed for 240VAC single-phase systems with hardwired input and output connections, it features an internal static bypass, multilingual graphical LCD, sealed lead-acid batteries (20 x 7 Ah) with hot-swappable replacement and support for extended battery packs. Communications include USB, RS-232 and mini-terminal blocks plus one expansion slot for Network-M2/Network-MS/ModBus-MS/relay-MS cards; compatible with Eaton Intelligent Power Manager and Intelligent Power Protector. Key specs: 6000 VA / 5400 W (PF 0.9), on-line double conversion with PFC, 575 x 244 x 542 mm (H x W x D), 65.5 kg, certified to IEC/EN 62040 series and relevant CE/CB/RCM standards. |
| Form Factor | Tower, free-standing |
| Noise Level | <45 dB at 1 meter |
| Part Number | 9SX6KI-AU |
| Weight (kg) | 65.5 kg |
| Battery Type | Sealed, lead-acid |
| Input Wiring | Single-phase (1-phase 3-wire), hardwired |
| Sub-Category | Power Equipment |
| Product Title | Eaton 9SX 6000VA / 5400W On-Line Tower UPS (9SX6KI-AU) - 240V, Hardwired |
| Expansion Slots | 1 slot for optional Network-M2, Network-MS, ModBus-MS or relay-MS card |
| Output Waveform | Sine wave |
| Runtime (up to) | Approx. 6 minutes at full load (manufacturer runtime varies with load and configuration) |
| Battery Quantity | 20 |
| Input Connectors | Hardwired |
| Output Frequency | 50/60 Hz |
| Power Rating (W) | 5400 W |
| Output Connectors | Hardwired |
| Power Rating (VA) | 6000 VA |
| Relative Humidity | 0–96% non-condensing |
| Communication Ports | 1 x USB, 1 x RS-232, 1 x mini-terminal block for remote Power Off, 1 x mini-terminal block for output relay |
| Input Voltage Range | 180–276 V without derating (up to 120–276 V with derating) |
| Output Power Factor | 0.9 |
| Battery Capacity (Ah) | 7 Ah |
| Includes Network Card | No |
| Input Frequency Range | 40–70 Hz |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Software Compatibility | Eaton Intelligent Power Manager; Eaton Intelligent Power Protector |
| Input Voltage (nominal) | 240 V |
| Output Voltage (nominal) | 240 V (configurable 200/208/220/230/240 V per documentation) |
| Dimensions (H x W x D mm) | 575 x 244 x 542 mm |
| Input Frequency (nominal) | 50/60 Hz |
| Extended Battery Capability | Yes (supports external/extended runtime packs) |
| Certifications and Compliance | CE Marked, CB, RCM; IEC/EN 62040-1, IEC/EN 62040-2, IEC/EN 62040-3, IEC 61000 |
| Battery Replaceable (hot-swappable) | Yes (battery replacement hot-swappable) |
Eaton 9SX 6000VA/5400W On Line Tower UPS, 240V
