Startech Usb To Displayport Adapter - 4k 30hz - Usb 3.0 - Usb Display Adapter - Dual Monitor Adapter -
QUICK OVERVIEW
This USB to DisplayPort adapter lets you connect your computer to a 4K DisplayPort monitor using a USB 3.0 Type-A port, even if your computer doesn’t support 4K video.
Increase your productivity by adding a 4K display
This USB to DP adapter can boost your productivity by providing more screen space to work with. Having multiple displays gives you the freedom to access two full-screen applications simultaneously, enabling you to reference material on one display while composing on another. The adapter even supports display rotation for a vertical screen that’s ideal for viewing spreadsheets, newsfeeds or stock tickers.
Easy-to-install
The multi-monitor adapter is powered by your computer's USB Type-A port, so you won’t need to connect a bulky external power adapter. Plus, the drivers install quickly and easily and only need to be installed once, regardless of how many USB video adapters you want to connect.
Get astonishing picture quality with 4K video
Even if your system doesn’t natively support 4K video output, this USB video adapter lets you enjoy the picture quality of Ultra HD video. With support for 4K at 30Hz, you get sharp and crisp picture quality that’s richer and more true-to-life than traditional HD, with far greater detail in both darker and brighter images.
The USB32DPES2 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
| Performance | |
| Audio Specifications | 2-channel stereo |
| General Specifications | This USB video adapter uses a Trigger family chipset. If you?re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset. |
| Maximum Digital Resolutions | 4K x 2K @ 30Hz |
| Supported Resolutions | Widescreen(16/32 bit): 3840?2160, 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720 Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480 |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Cable Length | 200 mm [7.9 in] |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 16 mm [0.6 in] |
| Product Length | 75 mm [3 in] |
| Product Weight | 58 g [2 oz] |
| Product Width | 55 mm [2.2 in] |
| Power | |
| Power Source | USB-Powered |
| Software | |
| Microsoft WHQL Certified | Yes |
| OS Compatibility | Windows? 10 (32/64) Windows 8 / 8.1 (32/64) Windows 7(32/64) |
| Special Notes / Requirements | |
| Note | This USB video adapter is not intended for graphical intensive applications |
| This USB video adapter uses a Trigger family chipset. If you?re connecting this device to a computer along with additional USB video adapters or docking stations, avoid using devices with different family chipsets, such as DisplayLink? or Fresco Logic? | |
| System and Cable Requirements | For 1 ~ 2 video adapters - CPU: Intel? Core? i3 2.8 GHz or equivalent (Core i5 recommended for HD video) - RAM: 2 GB or more (4 GB recommended for HD video) For 3 ~ 4 video adapters - CPU: Intel Core i5 Quad Core 2.8 GHz or equivalent - RAM: 4 GB or more For 5 video adapters - CPU: Intel Core i7 Quad Core 3.0 GHz or equivalent - RAM: 8 GB or more |
| What's in the Box | |
| Included in Package | quick-start guide |
| USB video adapter | |
| Packaging Information | |
| Shipping (Package) Weight | 190 g [6.7 oz] |
| Hardware | |
| USB Pass-Through | No |
| Ports | 1 |
| Output Signal | DisplayPort |
| Memory | DDR 4Gb |
| Chipset ID | MCT - T6-688L |
| Audio | Yes |
| Environmental | |
| Storage Temperature | -15?C to 75?C (5?F to 167?F) |
| Operating Temperature | 0?C to 45?C (32?F to 133?F) |
| Humidity | < 85% non-condensing |
| Connector(s) | |
| Connector B | DisplayPort (20 pin) Female Output |
| Connector A | USB Type-A (9 pin) USB 3.0 Male Input |
| Marketing Text | This USB to DisplayPort adapter lets you connect your computer to a 4K DisplayPort monitor using a USB 3.0 Type-A port, even if your computer doesnt support 4K video. |
| PI Date | Feb 2018 |
| Brand Name | Startech |
| Manufacturer Web Site | http://www.startech.com |
| Product Type | Adapter |
| Cable Color | Black |
| Cable Length | 0.2meter |
| Depth (mm) | 75.0 |
| Height (mm) | 16.0 |
| Width (mm) | 55.0 |
| Weight (Grams) | 58.0 |
| Compliance Standrards | * RoHS |
| Operating Temperature | 0 to 45°C |
| Other Features | * Audio Specifications: 2-channel stereo * Maximum Digital Resolutions: 4K x 2K @ 30Hz * Chipset ID: MCT - T6-688L * Memory: DDR 4Gb |
| Warranty Information | 2 Year |
