Alta Labs | S24-POE 24-Port Enterprise Network Switch, 16 port support PoE+ & 2xSFP port, 240W PoE with AU plug
The Alta Labs S24-POE is a professional-grade 24-port Gigabit Ethernet switch engineered for high-performance connectivity in enterprise, small office, and home office environments. This versatile switch features 16 PoE+ ports, each capable of delivering up to 30W, supported by a substantial 240W total power budget. It is designed to effortlessly power demanding hardware such as IP cameras, VoIP phones, and wireless access points.
Equipped with two high-speed SFP+ ports, the S24-POE provides lightning-fast fibre uplinks to ensure reliable data transfer across your network. Advanced networking capabilities including VLAN stacking, IGMP snooping, and rate limiting are integrated to provide optimal security and traffic management. These features allow for a more stable and tailored network experience for users with high-bandwidth requirements.
The unit features a fanless design, ensuring completely silent operation which makes it an ideal choice for noise-sensitive workspaces or home installations. Its durable SGCC steel construction with a matte powder-coated finish ensures longevity, while the inclusion of Bluetooth setup functionality allows for a quick and hassle-free commissioning process via mobile devices.
Flexible installation options are provided with support for both rack-mounting and wall-mounting, allowing the S24-POE to adapt seamlessly to your existing infrastructure. Combining high switching capacity with energy efficiency and robust build quality, this switch is a premier solution for modern networking needs that require both power and precision.
FEATURES
- 24 Gigabit Ethernet ports
- 16 PoE+ ports with up to 30W per port
- 240W total PoE budget
- 2 SFP+ ports for high-speed fibre connectivity
- Fanless, quiet operation for noise-sensitive environments
- Advanced networking including VLAN stacking and IGMP snooping
- Bluetooth setup for quick and easy mobile installation
- Rack-mountable and wall-mountable SGCC steel design
SPECIFICATIONS
- Dimensions: 44mmx254mmx441.5mm
- Weight: 3.6kg
- Material: SGCC steel with matte powder-coated finish
- Switching Capacity: 88Gbps
- Non-blocking Throughput: 44Gbps
- Forwarding Rate: 65.5Mpps
- PoE Standard: 802.3at PoE+ (backwards compatible with 802.3af)
- Power Consumption (without PoE): 53W
- Power Consumption (with full PoE load): 295W
- Operating Temperature: -5 C to 50 C
- Operating Humidity: 10%-90% non-condensing
- Certifications: FCC, CE, IC
- Product Code: S24-POE
WARRANTY
2-Year Limited Warranty
