Volans Aluminium Usb-c To 4k Hdmi Multi-function Adapter With Power Delivery Lan And Usb-a Port Vl-uch3cl

SKU
261576
Brand
MPN
VL-UCH3CL
Warranty
1 Year Manufacturer's return to base
Availability
Preorder (Contact Us)
Freight Estimate
$28.00
Buy Now And Earn 28 Reward Points!

Features

Easy-to-use USB-C cable

This multiport USB-C adapter converts the video, data, and power input capabilities of your laptop’s USB-C port into five individual ports. With additional connectivity, you can save money and use the adapter with your existing peripherals, instead of having to purchase new devices. Plus, it offers a built-in, easy-to-use USB Type-C cable, so you will be able to connect to your laptop without having to carry around a separate host cable. The next-generation USB-C cable is small and reversible, which makes it easier to insert into your laptop. You can connect the plug with either side facing up, so there’s less risk of damaging your laptop port. Plus, because it uses USB-C, the adapter is Thunderbolt™ 3 port compatible, so you can connect it to your Thunderbolt 3 equipped laptop. Now, you can spend more time working, and less time setting up your workstation.

More convenience with power and port design

If you’re tired of connecting or carrying multiple power adapters with you when you travel, then this multi-port adapter can help. It features a USB-C port that supports both USB Power Delivery 2.0 (USB PD 2.0) and data transfer, so you can use your laptop’s USB-C power adapter to power both your laptop, and the multi-port adapter or transfer data from a type-c drive to your laptop. The versatile multi-port adapter is compact and lightweight, making travel easier and more convenient, so you can set up a workstation virtually anywhere you work or visit. Because it consolidates multiple ports into a single adapter, you eliminate the need to connect or travel with multiple single-function adapters.

Easily connect a 4K Ultra HD display, and two USB 3.0 devices

When coupled with your laptop display, this versatile USB-C multi-port adapter makes it easy to create a dual-monitor workstation when you need it. It offers a 4K HDMI® (with audio) port, so you can easily connect a high-resolution monitor and gain access to more screen space. With higher resolutions, you can view more windows at once and increase your overall productivity. With two additional USB 3.0 ports, as well as Gigabit Ethernet, the adapter gives you the vital connectivity you need when you’re in the office or when you travel. And because it features USB-A ports, you can connect your current peripherals and avoid the added cost of purchasing a newer USB-C device.

Specification

WARRANTY INFORMATION
  Warranty 1 Year
HARDWARE
  4K Support Yes
  Bus Type USB-C
  Chipset ID VIA – VL817
VIA – VL102
Realtek – RTL8153
Parade – PS176
  Displays Supported 1
  Fast-Charge Port(s) No
  Industry Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 – Backward compatible with USB 2.0 and 1.1
PERFORMANCE
  Auto MDIX Yes
  Compatible Networks 10/100/1000 Mbps
  Full Duplex Support Yes
  Maximum Data Transfer Rate 5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
  Maximum Digital Resolutions 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
  Type and Rate USB 3.0 – 5 Gbit/s
  UASP Support Yes
CONNECTOR(S)
  Connector Type(s) 1 – USB Type-C (24 pin) USB 3.0 Male
    1 – HDMI (19 pin) Female
    1 – RJ-45 Female
    2 – USB Type-A (9 pin) USB 3.0 Female
    1 – USB Type-C (24 pin) USB 3.0 Female
SOFTWARE
  OS Compatibility Windows® 7, 8, 8.1, 10
Mac OS® 10.9 to 10.13
Chrome OS™
SPECIAL NOTES / REQUIREMENTS
  Note Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP alt mode.
    The adapter can connect to a host laptop’s USB-C port that doesn’t support USB Power Delivery 2.0. However, in this configuration if a power adapter is connected to the multifunction adapter, it will not pass power through to your host laptop.
    A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K)
    USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps.
    Your laptop might have specific charging requirements. For example, if your laptop requires exactly 60W of power and an adapter consumes some of the 60W, your laptop might not recognize that it is getting enough power. For more information about Power Delivery, refer to the manufacturer of your hardware.
  System and Cable Requirements A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 2.0 and DP alt mode)
    Optional: USB-C power adapter (for example, your laptop’s USB-C based power adapter)
POWER
  Power Delivery 60W
  Power Source USB-Powered
ENVIRONMENTAL
  Humidity 0~85% RH (Non-condensing)
  Operating Temperature 0°C to 50°C (32°F to 122°F)
  Storage Temperature -10°C to 65°C (14°F to 149°F)
PHYSICAL CHARACTERISTICS
  Color Black
  Enclosure Type Aluminium & ABS
WHAT’S IN THE BOX
  Included in Package 1 – UCH3CL
    1 – quick-start guide
