Output
Nominal Output Voltage 230V
Maximum Total Current Draw per Phase 16A
Output Connections
(20) IEC 320 C13 IEC 320 C13
(4) IEC 320 C19 IEC 320 C19
Input
Nominal Input Voltage 200V, 208V, 230V
Input Frequency 47 - 63 Hz
Input Connections
IEC 309 16A
Cord Length 3.05 meters
Number of Power Cords 1
Maximum Input Current per phase 16A
Load Capacity 3680 VA
Physical
Net Weight 5.57 KG
Maximum Height 1619.00 mm
Maximum Width 56.00 mm
Maximum Depth 44.00 mm
Shipping Weight 6.48 KG
Shipping Height 2134.00 mm
Shipping Width 152.00 mm
Shipping Depth 127.00 mm
Color Black
Environmental
Operating Environment -5 - 45 ?C
Operating Relative Humidity 5 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -25 - 65 ?C
Storage Relative Humidity 5 - 95%
Storage Elevation 0-15000 meters
Conformance
Regulatory Approvals CE, VDE
Standard Warranty 2 years repair or replace
Sustainable Offer Status
RoHS Compliant
REACH REACH: Contains SVHCs
PEP Available in Documentation tab
EOLI Available in Documentation tab
Other Environmental Compliance China RoHS
Toolless Rack Mounting Capabilities Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Vertical Mounting Capabilities Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
Basic Rack PDU Features & Benefits
Agility
Rack-Mountable Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Single input power source Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Wide range of input and output connections Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Total Cost of Ownership
Low Cost Power Distribution Provides a number of outlets to bring power to rack equipment at an affordable price.
