Output
Nominal Output Voltage 230V
Maximum Total Current Draw per Phase 16A
Output Connections
(20) IEC 320 C13 IEC 320 C13
(4) IEC 320 C19 IEC 320 C19
Input
Nominal Input Voltage 200V, 208V, 230V
Input Frequency 50/60 Hz
Input Connections
IEC 309 16A 2P+E
Cord Length 0.91 meters
Number of Power Cords 1
Maximum Input Current per phase 16A
Load Capacity 3680 VA
Physical
Net Weight 4.86 KG
Maximum Height 1619.00 mm
Maximum Width 56.00 mm
Maximum Depth 44.00 mm
Shipping Weight 5.77 KG
Shipping Height 2134.00 mm
Shipping Width 152.00 mm
Shipping Depth 127.00 mm
Color Black
Environmental
Operating Environment 0 - 45 ?C
Operating Relative Humidity 5 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -25 - 65 ?C
Storage Relative Humidity 5 - 95%
Storage Elevation 0-15000 meters
Conformance
Regulatory Approvals CE, GOST, IRAM, VDE
Standard Warranty 2 years repair or replace
Sustainable Offer Status
RoHS Compliant
PEP Available in Documentation tab
EOLI Available in Documentation tab
Other Environmental Compliance China RoHS
