Output
Nominal Output Voltage 230V
Maximum Total Current Draw per Phase 32A
Output Connections
(8) IEC 320 C13 IEC 320 C13
(2) IEC 320 C19 IEC 320 C19
Overload Protection Yes
Input
Nominal Input Voltage 230V
Input Frequency 50/60 Hz
Input Connections
Hard Wire 3 wire (1PH+N+G)
IEC-320 C20
Number of Power Cords 1
Maximum Line Current per phase 32A
Maximum Input Current per phase 32A
Load Capacity 7680 VA
Load Power Factor Range 0 to 1
Physical
Net Weight 11.36 KG
Maximum Height 89.00 mm
Maximum Width 432.00 mm
Maximum Depth 660.00 mm
Shipping Weight 23.18 KG
Shipping Height 203.00 mm
Shipping Width 610.00 mm
Shipping Depth 991.00 mm
Color Black
Units per Pallet 10.00
Environmental
Operating Environment -20 - 50 ?C
Operating Relative Humidity 0 - 95%
Operating Elevation 0-4500 meters
Storage Temperature -25 - 65 ?C
Storage Relative Humidity 0 - 95%
Storage Elevation 0-15000 meters
Conformance
Regulatory Approvals CSA, EN 60950, GOST, IEC 60950, IEC 60950, UL 1778
Standard Warranty 2 years (parts only)
