SMX120BP Features
Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
User-replaceable batteries Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging.
Scalable runtime Allows additional run time to be quickly added as needed.
Rack/Tower convertible Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Output
battoutvolt 120
Batteries & Runtime
Battery Volt-Amp-Hour Capacity 1200
Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Battery mounting Enclosed battery cartridge
Battery manufacturer --
Expected Battery Life (years) 3 - 5
RBC™ Quantity 2
Battery blocks per string 10
Physical
Net Weight 60.91 KG
Maximum Height 432.00 mm
Maximum Width 178.00 mm
Maximum Depth 483.00 mm
Shipping Weight 65.45 KG
Shipping Width 586.00 mm
Shipping Height 330.00 mm
Shipping Depth 633.00 mm
Rack Height 4U
Color Black
Units per Pallet 6.00
Environmental
Operating Environment 0 - 40 ?C
Operating Relative Humidity 0 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -15 - 45 ?C
Storage Relative Humidity 0 - 95%
Storage Elevation 0-15000 meters
Conformance
Standard Warranty 2 years repair or replace
Sustainable Offer Status
RoHS Compliant
REACH REACH: Contains No SVHCs
