Output
Output Power Capacity 1980 Watts / 2200 VA
Max Configurable Power 1980 Watts / 2200 VA
Nominal Output Voltage 230V
Output Voltage Distortion Less than 5%
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Other Output Voltages 208, 220, 240
Topology Line Interactive
Waveform Type Sine wave
Output Connections
(8) IEC 320 C13
(2) IEC 320 C19
(2) IEC Jumpers
Input
Nominal Input Voltage 208V, 230V
Input Frequency 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C20
Schuko CEE 7 / EU1-16P
British BS1363A
Cord Length 1.83 meters
Input voltage range for main operations 140 - 280V
Other Input Voltages 220, 240
Transfer Time 2-4 ms
Interface Port(s) SmartSlot, USB
Available SmartSlot™ Interface Quantity 1
Control panel LED status display with On Line : On Battery : Replace Battery and Overload indicators, Multi-function LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO) Yes
Surge Protection and Filtering
Surge energy rating 645 Joules
Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Data Line Protection --
Physical
Maximum Height 432.00 mm
Maximum Width 178.00 mm
Maximum Depth 483.00 mm
Rack Height 4U
Net Weight 38.64 KG
Shipping Weight 47.73 KG
Shipping Height 330.00 mm
Shipping Width 586.00 mm
Shipping Depth 633.00 mm
Color Black
Units per Pallet 6.00
# of Layers per Pallet 4
# of Units per Layer per Pallet 2
Pallet Weight 388.69 KG
Environmental
Operating Environment 0 - 40 ?C
Operating Relative Humidity 0 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -15 - 45 ?C
Storage Relative Humidity 0 - 95%
Storage Elevation 0-15000 meters
Audible noise at 1 meter from surface of unit 55.00 dBA
Online Thermal Dissipation 150.00 BTU/hr
Conformance
Regulatory Approvals C-tick, CE, CSA, EN 50091-1, EN 50091-2, FCC Part 15 Class A, GOST, IEC 60950, IRAM, UL 1778, VDE
Standard Warranty 3 years repair or replace (excluding battery) and 2 year for battery, optional on-site warranties available, optional extended warranties available
Sustainable Offer Status
RoHS Compliant
REACH REACH: Contains No SVHCs
