ASUSTOR 4-BAY NAS 3.5"/2.5"(0/4), QC-2.1GHz, 8GB, GbE LAN(1), 2.5G(2), PCIe, 1RU, 3YR AS6504RS
SKU
430293
Brand
MPN
AS6504RS
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,454.00
Buy Now And Earn 1454 Reward Points!
Intel Atom C3538 2.1GHz Quad-Core CPU 8 GB DDR4-2133 - 128 GB maximum Two Gigabit Ethernet and two 2.5-Gigabit Ethernet ports. Can provide up to 5 gbps when aggregated. Supports Wake-on-LAN and Wake-on-WAN Complete iSCSI/IP-SAN and NFS support - Supports VMware, Citrix and Hyper-V - Supports virtual machines and Docker applications Supports ACL and AD. Improves business application efficiency. PCIe slot for 10-Gigabit Ethernet card
| CPU Model | Intel ATOM C3538 |
| CPU Architecture | x64 64-bit |
| CPU Frequency | Quad-Core 2.1GHz |
| Memory | 8GB SO-DIMM DDR4 |
| Memory Module Pre-installed | 8GB (1x 8GB) |
| Total Memory Slots | 4 |
| Memory Expandable up to | 128GB (4x 32GB) |
| Flash Memory | 8GB eMMC |
| Drive Bays | 4 |
| Compatible Drive Type | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
| Maximum Drive Bays with Expansion Unit | 20 |
| Supports Hot Swappable Drives | Yes |
| Expansion | 4x USB 3.2 Gen 1 |
| Network | 2x Gigabit Ethernet (1G/100M) 2x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
| PCIe Expansion Slots | PCIe 3.0 x8 slot (black, x4 link) |
| Multimedia Output | N/A |
| System Fan | 2x 40mm |
| Power Supply Unit / Adapter | AS6504RS: 250W x1 AS6504RD: 250W x2 AS6504RS x1 / AS6504RD x2 |
| Input Power Voltage | 100V to 240V AC |
| Redundant power supply | Yes |
| Service LED Indicator | Yes |
| Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS |
| Warranty | 3 Years |
| Power Consumption | AS6504RS: 47.7W (Operation) 28.4W (Disk Hibernation); AS6504RD: 65W (Operation) 42.4W (Disk Hibernation); |
| Noise Level | N/A |
| Operation Temperature | 0°C~40°C (32°F~104°F) |
| Storage Temperature | -20°C~70°C (-4°F~158°F) |
| Humidity | 5% to 95% RH |
| Size | 44(H) x 439(W) x 515(D) mm |
| Weight | AS6504RS: 7.85kg / 17.27 lbs; AS6504RD: 9.3 kg / 20.46 lbs |
ASUSTOR 4-BAY NAS 3.5"/2.5"(0/4), QC-2.1GHz, 8GB, GbE LAN(1), 2.5G(2), PCIe, 1RU, 3YR
