Allied Telesis 48V 480W Single Output Industrial Din Rail Power Supply AT-IE048-480-20
SKU
436422
Brand
MPN
AT-IE048-480-20
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$494.00
Buy Now And Earn 494 Reward Points!
Allied Telesis 48V 480W Single Output Industrial DIN RAIL Power Supply
| UPC | 767035216478 |
|---|---|
| Brand | Allied Telesis |
| Input | Wide AC input range (worldwide) |
| Model | IE048-480 |
| Series | IE048 Series |
| Weight | 2.65 lb (approx.) |
| Category | Power and Rack Equipment |
| Features | Active Power Factor Correction (PFC) Compact metal housing DIN-rail clip Ruggedized for harsh environments Electromagnetic compatibility and thermal design for industrial use |
| Material | Metal housing |
| Mounting | DIN rail mount |
| Dimensions | Depth: 4.6 in Width: 2.8 in Height: 4.9 in |
| Efficiency | 94% |
| Description | Ruggedized industrial AC/DC power supply delivering 480 W output at nominal 48 V DC (single output). Housed in a compact metal case with DIN-rail clip for industrial environments, the unit features high efficiency (94%), active Power Factor Correction (PFC), wide AC input range for worldwide use, and the ability to support 150% peak loads. Nominal 48 V output is adjustable to match application requirements. Suitable for surveillance/security, industrial Ethernet, transportation and other harsh-environment deployments. |
| Form Factor | DIN Rail |
| Applications | Smart Cities (surveillance & security) Industrial Ethernet Transportation Harsh-environment industrial systems |
| Output Power | 480 W |
| Product Type | Industrial AC/DC Power Supply |
| Sub-Category | Power Equipment |
| Product Title | Allied Telesis IE048-480 48V 480W Industrial DIN-Rail Power Supply (AT-IE048-480-20) |
| Output Current | 10 A |
| Output Voltage | 48 V DC (nominal, adjustable) |
| Country of Origin | China |
| Manufacturer Website | http://www.alliedtelesis.com |
| Output Configuration | Single output |
| Peak Load Capability | Supports 150% of peak load |
| Alternate Part Numbers | ATIE04848020 at-ie048-480-20 |
| Manufacturer Part Number | AT-IE048-480-20 |
Allied Telesis 48V 480W Single Output Industrial DIN RAIL Power Supply
