Achieve high-performance, long-distance network links with our Huawei-compatible 10G BiDi SFP+ Transceiver. This module is expertly engineered to transmit and receive data over a single strand of single-mode fibre, effectively doubling your network's capacity without the need to lay new fibre. It's an ideal, cost-effective solution for extending your network backbone, connecting data centres, or for use in enterprise and service provider networks that demand both speed and reliability over extended distances.

This transceiver utilises advanced Bi-Directional (BiDi) technology with a 1270nm DFB laser transmitter and a 1330nm PIN photodiode receiver. This allows for simultaneous two-way communication over one fibre core, significantly reducing cabling costs and complexity. The hot-pluggable SFP+ footprint means you can install or swap the module without shutting down your network equipment, ensuring maximum uptime and simplifying maintenance or upgrades.

Designed for seamless integration with Huawei networking gear, this transceiver is fully compliant with SFP+ MSA (Multi-Source Agreement) standards, guaranteeing interoperability and straightforward deployment. It supports data rates of up to 10.31Gbps across distances of up to 40km. With built-in Digital Diagnostics Monitoring (DDMI), you can access real-time data on temperature, laser power, and other critical parameters, enabling proactive network management and troubleshooting.

FEATURES

• Guaranteed 100% compatible with Huawei switches and routers
• Transmits 10G data rates up to 40km over single-mode fibre (SMF)
• Bi-Directional (BiDi) technology uses a single fibre to transmit and receive
• Hot-pluggable SFP+ form factor for installation without network interruption
• Integrated Digital Diagnostics Monitoring (DDMI) for real-time monitoring
• Low power consumption for an energy-efficient network

SPECIFICATIONS

• Data Rate: 10Gbps
• Form Factor: SFP+
• Wavelength: TX 1270nm / RX 1330nm
• Max Distance: 40km
• Fibre Type: Single-Mode Fibre (SMF)
• Connector: Simplex LC
• Transmitter: DFB Laser
• Receiver: PIN Photodiode
• DDMI/DOM: Supported
• Power Consumption: <1.5W
• Operating Temperature: 0 C to 70 C
• Protocols: MSA Compliant, IEEE 802.3ae (10GBASE-ER/EW)

WARRANTY

3-Years Limited Warranty
