Cambium 60GHz Bridge In A Box 2Gb With Anz Cord C600510C033B
SKU
406663
Brand
MPN
C600510C033B
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,750.00
Buy Now And Earn 1750 Reward Points!
Cambium 60GHz Bridge in a Box 2Gb with ANZ Cord
| MPN | C600510C033B |
|---|---|
| SKU | C600510C033B |
| Brand | Cambium Networks |
| Model | C600510C033B |
| Notes | Most sources list the product as a 2 Gbps Bridge-in-a-Box (MPN C600510C033B). Some listings identify the radio model as V2000 (cnWave) and report higher throughput (up to 3.6 Gbps) and additional 2.5 GbE details — those entries are provided here as variant information where cited. |
| Ports | 2.5 GbE PoE input; 2.5 GbE 802.3at PoE passthrough/output |
| Category | Networking |
| Security | 128-bit AES |
| Modulation | 16-QAM, BPSK |
| Beamforming | Auto-beamforming, ±10° horizontal, ±4.5° vertical (listed for V2000 variant) |
| Description | Cambium Networks Bridge-in-a-Box (C600510C033B) is a preconfigured, point-to-point 60 GHz wireless Ethernet bridge supplied as a pair of pre-paired outdoor radios. Designed to extend LAN connectivity from building to building or provide backhaul for Wi‑Fi/CCTV and remote sites, the system supports ranges from approximately 20 m to 8 km (50 ft to 5 miles) and delivers up to 2 Gbps aggregate throughput. Each kit includes the radio modules, Power over Ethernet (PoE) injector(s), mounting hardware and an ANZ power cord (as specified by some suppliers). The radios support cnMaestro cloud or on‑premises management, IPv4/IPv6, Layer 2 bridging and Layer 3 IPv6 routing, 128‑bit AES security, and industry VLAN/QoS standards for carrier and enterprise deployments. |
| Product type | Outdoor Point-to-Point Wireless Bridge |
| Sub-Category | Wireless Networking |
| Mounting type | Pole mount (mounting hardware included) |
| Product Title | Cambium Networks Bridge-in-a-Box 60 GHz 2Gb (C600510C033B) |
| Antenna design | Internal |
| Frequency band | 57 - 66 GHz |
| Product colour | White |
| Antennas quantity | 1 per radio (pair included) |
| Antenna gain (max) | 34.5 dBi |
| Ethernet interfaces | 2.5 GbE PoE input and 2.5 GbE 802.3at PoE output (supports 100 / 1000 / 2500 Mbps) |
| Supported protocols | IPv4, IPv6, Layer2 Bridge, Layer3 IPv6 Routing, Open/R Distributed Networking |
| Wireless technology | 60 GHz cnWave / 802.11ay (Terragraph referenced by some sources) |
| Included accessories | Pair of pre-configured radio modules, PoE injector(s), mounting hardware, ANZ power cord (as specified by some sources) |
| Net weight (product) | 5.4 kg |
| Networking standards | IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1p |
| Operating temperature | -40 to 60 °C |
| Dimensions (H x W x D) | 30.5 cm x 25 cm x 40 cm |
| Gross weight (package) | 5.41 kg |
| Management / protocols | cnMaestro, HTTP, HTTPS, SNMP v2c & v3 |
| Use cases / applications | Building-to-building LAN extension, remote Wi‑Fi hotspots, backhaul for Wi‑Fi or small cells, CCTV/video feeds, temporary events, remote buildings and campus links |
| Alternate model / variant | V2000 (cnWave) listed by some sources |
| Power over Ethernet (PoE) | Yes |
| Maximum data transfer rate | 2000 Mbit/s (2 Gbps) (common listing) |
| Power consumption (typical) | 18 W |
| Manufacturer link / resources | Datasheet and product materials referenced from Cambium Networks (manufacturer) |
| Alternate throughput (V2000 variant) | Up to 3.6 Gbps (1.8 Gbps DL + 1.8 Gbps UL) — listed for V2000 variant by some sources |
Cambium 60GHz Bridge in a Box 2Gb with ANZ Cord
