CAT6 RJ45 Keystone Jack with Dust Shutter 90° | 10 Pack White

Compatible with keystone faceplates, surface mount boxes and patch panels*. Can be used with Australian HPM and CLIPSAL plates with the use of a bezel. Unique patented removable dust caps are handy to protect your outlets when not in use.

*Due to the proximity of each port on a patch panel, if you try and use these jacks for the majority of the ports you may come across an issue of not being able to physically fit them all in.

FEATURES
Dual T568A and T568B Wiring
RJ45 Complies with FCC Part 68 Standard
110/ Krone dual IDC connector compatible
Provides termination for 22-26 AWG Wire
Jack insertion life > 750 mating cycles
IDC insertion life > 250 mating cycles
Operating temperature -40 to + 60°C
Unique patented removable dust caps to protect it from dust when not in use
SPECIFICATIONS
CAT6
Unshielded
Colour: White
Qty in Pack: 10
Gold-Plating: 1.27um/50u inch
IDC insertion life: > 250 mating cycles
Jack insertion life: > 750 mating cycles
Operating temperature: -40 to + 60 degrees Celsius
Contact: 0.46mm Diameter Phosphor Bronze Gold Plated over Nickel
Dielectric withstanding voltage: 1000v
Insulation Resistance: 500m Ohm
Contact resistance: 20m Ohm
DC resistance: Max 0.1 Ohm
DC Current rating: 1.5Amps
WARRANTY

3-years limited warranty
