Cisco Catalyst 9300 24-port UPOE Network Advantage C9300-24U-A
SKU
296655
Brand
MPN
C9300-24U-A
Warranty
Standard Manufacturer's Warranty
$6,252.00
Buy Now And Earn 6252 Reward Points!
The Cisco Catalyst 9300 Series Switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry's most widely deployed switching platform. The Catalyst 9300 Series switches form the foundational building block for Software-Defined Access
| General Information | |
|---|---|
| Product Type: | Ethernet Switch |
| Manufacturer Part Number: | C9300-24U-A |
| Manufacturer Website Address: | http://www.cisco.com/c/en_au |
| Manufacturer: | Cisco Systems, Inc |
| Product Model: | C9300-24U |
| Product Name: | Catalyst 9300 24-port UPOE, Network Advantage |
| Product Line: | Catalyst |
| Product Series: | 9300 |
| Brand Name: | Cisco |
| Interfaces/Ports | |
|---|---|
| Modular: | No |
| Uplink Port: | Yes |
| Stack Port: | Yes |
| Total Number of Network Ports: | 24 |
| Port/Expansion Slot Details: | 24 x Gigabit Ethernet Network |
| Management & Protocols | |
|---|---|
| Manageable: | Yes |
| Media & Performance | |
|---|---|
| Network Technology: | 10/100/1000Base-T |
| Ethernet Technology: | Gigabit Ethernet |
| Media Type Supported: | Twisted Pair |
| Miscellaneous | |
|---|---|
| Environmentally Friendly: | Yes |
| Network & Communication | |
|---|---|
| Layer Supported: | 2 |
| Physical Characteristics | |
|---|---|
| Weight (Approximate): | 7.54 kg |
| Form Factor: | Rack-mountable |
| Height: | 43.9 mm |
| Width: | 444.5 mm |
| Depth: | 444.5 mm |
| Power Description | |
|---|---|
| Power Source: | Power Supply |
| Redundant Power Supply Supported: | |
| Marketing Text | The Cisco Catalyst 9300 Series Switches are Cisco's lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry's most widely deployed switching platform. The Catalyst 9300 Series switches form the foundational building block for Software-Defined Access |
| PI Date | Oct 2017 |
| Brand Name | Cisco |
| Manufacturer Web Site | http://www.cisco.com |
| Product Line | Catalyst |
| Product Model | C9300-24U |
| Product Type | Switch |
| Switching Fabric | 208Gbps |
| Forwarding Rate | 154.76 Mpps |
| Packet Buffer | 16MB |
| Mac Address | 32Kentries |
| Jumbo Frame Size | 9198Bytes |
| Stacking Speed | 480Gbps |
| Gigabit Ethernet Port | Yes |
| No. of Ports | 24 |
| Type | 10/100/1000 |
| Console Ports | 1 |
| Output Power | 830Watt |
| Depth (mm) | 445.0 |
| Height (mm) | 44.0 |
| Width (mm) | 445.0 |
| Weight (Kg) | 7.5 |
| Layer Support | 2 - 3 |
| Management Features | * Element management * Unified management of wired and wireless networks |
| Memory | 8GB |
| Network Technology | 10/100/1000 |
| PoE Enabled | Yes |
| MTBF | 238410hours |
| VLAN | * VLAN IDs: 4000 * Per-VLAN Rapid Spanning Tree (PVRST+) allows rapid spanning tree (IEEE 802.1w) reconvergence on a per-VLAN spanning tree basis, providing simpler configuration than MSTP. In both MSTP and PVRST+ modes, stacked units behave as a single spanning tree node. |
| Security Features | * MACsec-256 * Encrypted Traffic Analytics (ETA) |
| Quality of Service (QoS) | * Static QoS configuration and monitoring * QoS scale entries: 5120 |
| Diagnostics LED | * "AC OK": Input power to the power supply is OK * "PS OK": Output power from the power supply is OK |
| Multi-Cast Features | * Multicast routing scale: 8000 * Multicast DNS (mDNS) gateway |
| Other Features | * Up to 480 Gbps of local stackable switching bandwidth * Flexible downlink options with 1G and Multigigabit links * Intelligent Power Management with Cisco StackPower technology, providing power stacking among members for power redundancy |
