Cisco - Catalyst 9200 24-port PoE+, Network Essentials C9200-24P-E
SKU
293106
Brand
MPN
C9200-24P-E
Warranty
Standard Manufacturer's Warranty
$4,261.00
Buy Now And Earn 4261 Reward Points!
Cisco Catalyst 9200 - Network Essentials - switch - L3 - smart - 24 x 10/100/1000 (PoE+) - rack-mountable - PoE+
DNA LICENSE MANDATORY
DNA LICENSE MANDATORY
| Ports | 24 x 10/100/1000 (PoE+) |
| Power | AC 120/230 V (50 - 60 Hz) |
| Weight | 5.5 kg |
| Subtype | Gigabit Ethernet |
| Capacity | Virtual networks: 4 ? IPv4 routing table entries: 4000 ? IPv6 routing table entries: 2000 ? ACL scale entries: 1600 ? Packet buffer size: 6 MB ? VLAN IDs: 4096 ? Switched virtual interfaces (SVIs): 1000 |
| Features | Cisco StackWise Technology, EIGRP Stub Routing, Flexible NetFlow (FNF), MACsec support, built-in ASIC, Control plane protection (CoPP), Blue Beacon LED, Embedded Event Manager (EEM), Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, DNA support, Superior QoS |
| Device Type | Switch - 24 ports - L3 - smart - stackable |
| Performance | Stacking bandwidth: 160 Gbps ? Switching bandwidth: 128 Gbps ? Forwarding rate: 190.4 Mpps |
| Enclosure Type | Rack-mountable |
| Power Redundancy | Optional |
| Routing Protocol | OSPF, RIP-1, RIP-2, VRRP, PIM-SSM, policy-based routing (PBR), RIPng |
| Dimensions (WxDxH) | 4.4 cm x 44.5 cm x 35 cm |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz |
| Jumbo Frame Support | 9198 bytes |
| Product Description | Cisco Catalyst 9200 - Network Essentials - switch - 24 ports - smart - rack-mountable |
| Manufacturer Warranty | Limited lifetime warranty |
| MAC Address Table Size | 32000 entries |
| Power Over Ethernet (PoE) | PoE+ |
| Remote Management Protocol | NETCONF, RESTCONF |
Cisco Catalyst 9200 - Network Essentials - switch - L3 - smart - 24 x 10/100/1000 (PoE+) - rack-mountable - PoE+
