The GLC-BX-U 1000Base-BX10 SFP Module is compatible with the IEEE 802.3ah 1000BASE-BX10-U standard, operate on a single strand of standard single-mode fiber.
The GLC-BX-U SFP also support digital optical monitoring (DOM) functions according to the industry-standard SFF-8724 Multi Source Agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.
The GLC-BX-U SFP also support digital optical monitoring (DOM) functions according to the industry-standard SFF-8724 Multi Source Agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.
| Product Type | SFP (mini-GBIC) |
| Brand Name | Cisco |
| Maximum Data Transfer Rate | 1 |
| Media Type Supported | Optical Fiber |
| Total Number of Ports | 1 |
| Manufacturer Part Number | GLC-BX-U= |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | GLC-BX-U |
| Product Name | GLC-BX-U 1000Base-BX10 SFP Module |
| Interfaces/Ports Details | 1 x LC 1000Base-BX |
| Connector Type | LC |
| Maximum Distance Supported | 10 km |
| Fiber Mode Supported | Single-mode |
| Additional Information | • Spare Product • The 1000BASE-BX-U SFP is compatible with the IEEE 802.3ah 1000BASE-BX10-U standard • A 1000Base-BX10-D device is always connected to a 1000Base-BX10-U device with a single strand of standard single-mode fiber. • 1310-nm TX/1490-nm RX wavelength • Transmit Power (dBm): -3 to -9 • Receive Power Range (dBm): -3 to -19.5 • Extended temperature range (EXT): 5°C to 85°C (23 to 185°F) • Surge Current: 30mA |
| Compatibility | Compatible Platform (Switches or Modules): • Catalyst 2960 series: • • WS-C2960-24TC-L • WS-C2960-48TC-L • WS-C2960G-24TC-L • Cisco ME 3400: • • ME-3400-24TS-A • ME-3400-24TS-D • Catalyst 3560 series: • • WS-C3560-24PS • WS-C3560-48PS • WS-C3560G-24TS • WS-C3560G-48TS • WS-C3560G-48PS • WS-C3560G-24PS • WS-C3560-48TS • WS-C3560-24TS • Catalyst 3750 series: • WS-C3750-24TS • WS-C3750-48TS • WS-C3750-24PS • WS-C3750-48PS • WS-C3750G-12S • WS-C3750G-24TS • WS-C3750G-48TS • WS-C3750G-24PS • WS-C3750G-48PS • WS-C3750G-12S • Catalyst 4500 series: • • WS-X4013+TS • WS-X4013+10GE • WS-4448-GB-SFP • WS-X4506-GB-T • WS-X4516-10GE • Catalyst 4900 series: • • WS-C4948 • Catalyst 6500 series: • • WS-SUP720 • WS-SUP32-8GE-3B • WS-SUP32-10GE-3B • WS-X6724-SFP • WS-X6748-SFP |
| Height | 8.5 mm |
| Width | 13.4 mm |
| Depth | 56.5 mm |
| Input Voltage | 3.5 V DC, 3.3 V DC, 3.1 V DC |
| Input Current | 200 mA |
| Application/Usage | Data Networking |
| Shipping Dimensions | Height 5, Width 24, Length 34, Shipping Weight 0.02 KG |
1000BASE-BX SFP 1310NM
