Nominal input voltage

PWR-RGD-AC-DC-H:
100 to 240 VAC, 50 to 60 Hz
100 to 250 VDC

PWR-RGD-LOW-DC-H:
24 to 60 VDC

Absolute maximum (short term) input voltage

PWR-RGD-AC-DC-H:
85 to 265 VAC, 47 to 63 Hz
88 to 300 VDC

PWR-RGD-LOW-DC-H:
18 to 75 VDC

Power consumption with PWR-RGD-AC-DC-H (s)

Single Power Supply Module installed:
No PoE ports on: 76W max/ 259.3 BTUs per hour
148W max / 505 BTUs per hour with maximum (4) PoE ports on,

Two Power Supply Modules installed:
PoE power consumption alone
(12 ports poe): 215W max / 733.6 BTUs per hour.

Complete system power including 12 ports poe: 291W max.

Power consumption with PWR-RGD-LOW-DC-H (s)

Single Power Supply Module installed:

No PoE ports on: 76W max/ 259.3 BTUs per hour

148W with maximum (4) PoE ports on, / 505 BTUs per hour

Two Power Supply Modules installed:
PoE power consumption alone
(12 ports poe): 215W max / 733.6 BTUs per hour.
Complete system power including 12 ports poe: 291W max.

Maximum PoE power available to Powered Devices (PD), with two power supply modules installed

Not to exceed: 185W total, with a limit of 30W max power per port for IEEE802.3at (POE+) powered devices and 15.4W max power per port for IEEE802.3af (POE) powered devices.

Weight
PWR-RGD-AC-DC-H
PWR-RGD-LOW-DC-H

2.55 lb (1.15 kg)
2.5 lb (1.13 kg)

Dimensions (H x W x D)

PWR-RGD-AC-DC-H and PWR-RGD-LOW-DC-H

1.58 x 7 x 5 in. (4 x 17.8 x 12.7 cm) (without mounting flanges)
1.58 x 8.15 x 5 in. (4 x 20.7 x 12.7 cm) (with mounting flanges)
