CyberPower Pfc Sinewave Short-Depth Series 1000VA / 600W Rackmount UPS - 1U - (CP1000EIPFCRM1U) 6V/7Ah*4, 6x Iec C13, 2 Yrs Adv. Rep & 2yrs On Int. Battery CP1000EIPFCRM1U
SKU
435410
Brand
MPN
CP1000EIPFCRM1U
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$664.00
Buy Now And Earn 664 Reward Points!
CyberPower Systems PFC Sinewave Short-Depth Series 1000VA / 600W Rackmount UPS - 1U -6x IEC C13 (2x Surge Protection only) 6V/7Ah*4 2 Yrs Adv. Replacement WTY Incl. internal Batteries - CP1000EIPFCRM1U.
Dimensions(WxHxD): 433 x 44 x 388.7mm
Dimensions(WxHxD): 433 x 44 x 388.7mm
| Brand | CyberPower |
|---|---|
| Color | Silver |
| Model | CP1000EIPFCRM1U |
| Notes | Outlets_Details_Source: Multiple sources list 6 x IEC C13 outputs; one source lists outlet distribution (battery & surge / critical / surge-only) — refer to manufacturer documentation for outlet grouping and load prioritization. |
| Phase | Single Phase |
| Features | Pure sine wave output Active PFC compatible Automatic Voltage Regulation (AVR) Color LCD panel USB connectivity PowerPanel management Short-depth chassis design GreenPower energy-saving technology Hot-swappable batteries SNMP/HTTP remote management capability (optional) |
| Topology | Line-interactive |
| Warranty | Limited 2 year warranty |
| Weight_kg | 13.43 |
| Capacity_VA | 1000 |
| Cord Length | 1.83 m |
| Description | The CyberPower CP1000EIPFCRM1U is a 1U rackmount, line-interactive UPS delivering 1000 VA / 600 W with pure sine wave output for equipment requiring active PFC power supplies. It features Automatic Voltage Regulation (AVR) for stabilized output, CyberPower GreenPower energy-saving technology, a color LCD for system status, and PowerPanel management software for local and remote monitoring. Built-in data-line protection supports high-speed Ethernet transmission up to 1 Gbps. The short-depth chassis optimizes rack space, while multiple IEC C13 outlets, hot-swappable sealed lead-acid batteries, and optional SNMP/HTTP network management provide flexible deployment for network, security, and electronic devices. |
| Form Factor | 1U rack-mountable (short-depth chassis) |
| LCD Display | Color LCD information display (power, battery, load, fault/warning) |
| Rack Height | 1U |
| Manufacturer | CyberPower Systems, Inc. |
| Product Line | PFC Sinewave |
| Product Type | Line-interactive UPS |
| Dimensions_mm | Depth: 388.6 Width: 433.1 Height: 43.9 |
| Input Current | 10 A |
| Input Voltage | 230 V AC |
| Product Title | CyberPower CP1000EIPFCRM1U 1000VA (600W) 1U Rackmount Line-Interactive UPS - Pure Sine Wave |
| Transfer Time | 10 ms |
| Waveform Type | Pure Sine Wave |
| Capacity_Watts | 600 |
| Certifications | CE |
| Output Voltage | 230 V AC ±5% |
| Product Series | E |
| Input Connector | IEC 60320 C14 (1) |
| Input Frequency | 50/60 Hz |
| Receptacle Type | IEC 60320 C13 |
| Output Frequency | 50/60 Hz |
| Package Contents | CP1000EIPFCRM1U UPS Rackmount ears Screw kit Power cord USB cable User's manual Quick start guide Function setup guide |
| Battery Chemistry | Sealed Lead Acid |
| Number of Outlets | 6 x IEC C13 |
| Output Connectors | IEC 60320 C13 (6) |
| Runtime_Full_Load | 2.2 minutes |
| Runtime_Half_Load | 10.5 minutes |
| Network Management | SNMP/HTTP remote monitoring (optional) |
| Management Software | PowerPanel Management Software (local and remote) |
| Output Power Factor | 0.6 |
| Plug/Connector Type | IEC 60320 C14 input / IEC 60320 C13 output |
| Replaceable Battery | Yes |
| Surge Energy Rating | 450 J |
| Thermal Dissipation | 18.4 BTU/h |
| Data-line Protection | RJ-45 Ethernet (supports up to 1 Gbps) |
| Additional Identifiers | Manufacturer Part/Item Number: 1253538 |
| Hot-swap/Serviceability | Hot-swappable batteries |
| Hot-swappable Batteries | Yes |
| Energy Saving Technology | GreenPower UPS energy-saving bypass |
| Environmental Compliance | RoHS (Restriction of Hazardous Substances) |
| Manufacturer Part Number | CP1000EIPFCRM1U |
| Transfer/Protection Features | Surge and spike protection Overload protection Data line protection (RJ-45) Audible alarm (UPS fault, battery mode, low battery, overload) |
| Typical Battery Recharge Time | 8 hours |
| Automatic Voltage Regulation (AVR) | Yes |
CyberPower PFC Sinewave Short-Depth Series 1000VA / 600W Rackmount UPS - 1U - (CP1000EIPFCRM1U) 6V/7Ah*4, 6x IEC C13, 2 Yrs Adv. Rep & 2yrs on Int. Battery
