TP-Link Outdoor 2.4GHz 300Mbps Wireless Cpe, Qualcomm, Up To 27dBm, 2T2R, 2.4GHz 802.11b/g/n, 9dBi Directional Antenna, 2 10/100Mbps Lan, Weather Proof, Passiv CPE210
SKU
393643
Brand
MPN
CPE210
Warranty
Standard Manufacturer's Warranty
$84.00
Buy Now And Earn 84 Reward Points!
TP-Link Outdoor 2.4GHz 300Mbps Wireless CPE, Qualcomm, up to 27dBm, 2T2R, 2.4GHz 802.11b/g/n, 9dBi directional antenna, 2 10/100Mbps LAN, Weather proof, Passive PoE, support TDMA and centralized management, WISP Client Router/AP/AP Client/Repeater/Bridge mode
| PoE | 24V Passive PoE adapter included; supports up to 60 m (200 ft) PoE deployment; allows remote reset |
|---|---|
| MIMO | 2x2 |
| Brand | TP-Link |
| Color | White |
| Model | CPE210 |
| Range | System-level optimizations for >5 km (paired PtP/PtMP) |
| Memory | 64 MB DDR2 RAM; 8 MB flash |
| Antenna | Built-in 9 dBi 2x2 dual-polarized directional MIMO antenna |
| Category | Networking |
| Warranty | 2 years |
| Processor | Qualcomm Atheros (reported values vary: 560 MHz MIPS 74Kc or MIPS 24KC 650 MHz) |
| Protocols | Ethernet, Fast Ethernet; TDMA mode with Pharos MAXtream |
| Dimensions | 8.82 x 3.11 x 2.36 inches (approx. 8.8 x 3.1 x 2.4 in) |
| Description | The TP-Link CPE210 is a cost-effective, weather-resistant outdoor CPE designed for long-range point-to-point (PtP) and point-to-multipoint (PtMP) wireless networking. It features a built-in 9dBi 2x2 dual-polarized directional MIMO antenna, adjustable transmit power up to 27 dBm, and system-level optimizations that enable paired links beyond 5 km. The device supports AP/Client/AP Router/AP Client Router (WISP) modes, TP-Link Pharos MAXtream TDMA for improved throughput and latency, and centralized management with Pharos Control. Passive 24V PoE deployment (PoE adapter included) and a rugged outdoor form factor make it suitable for outdoor Wi-Fi coverage and wireless bridge applications. |
| Form Factor | Pole-mountable / outdoor CPE |
| Item Weight | 7.2 ounces |
| Sub-Category | Wireless Networking |
| Input Voltage | 24 V DC |
| Product Title | TP-Link CPE210 2.4GHz N300 9dBi Outdoor CPE (300 Mbps) |
| Ethernet Ports | 1 x 10/100 Mbps shielded Ethernet (PoE in) |
| Frequency Band | 2.4 GHz (single-band) |
| Transmit Power | Adjustable, 0 to 27 dBm (up to 500 mW) |
| Operation Modes | AP, Client, AP Router, AP Client Router (WISP) |
| Package Contents | Outdoor Wireless CPE, 24VDC Passive PoE Adapter, Pole Mounting Straps, AC Power Cord, Installation Guide |
| Special Features | Long range, Point-to-Point/Point-to-MultiPoint support, Passive PoE, Centralized management (Pharos Control) |
| Country of Origin | China |
| Maximum Data Rate | 300 Mbps |
| Power Consumption | 10.5 W (max) |
| Wireless Standard | IEEE 802.11n |
| Included Components | Outdoor Wireless CPE (CPE210), 24V DC Passive PoE adapter (24V 1A), pole mounting straps, AC power cord, installation guide |
| Operating Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Security / Encryption | WPA, WPA2, WPA-PSK, WPA2-PSK, AES, TKIP, 64/128/152-bit WEP |
| Hardware Version (support page) | V3.28 (firmware and manuals available) |
| Environment / Weather Resistance | Weather-resistant outdoor design |
| Wireless Technologies / Features | Pharos MAXtream TDMA, Pharos Control centralized management |
TP-Link Outdoor 2.4GHz 300Mbps Wireless CPE, Qualcomm, up to 27dBm, 2T2R, 2.4GHz 802.11b/g/n, 9dBi directional antenna, 2 10/100Mbps LAN, Weather proof, Passiv
