CyberPower Pro Series 1500VA / 1350W (10A) Tower UPS With LCD -(Pr1500Elcd)- 3 Yrs Adv. Rep & 2 Yrs On Int. Battery PR1500ELCD
SKU
136180
Brand
MPN
PR1500ELCD
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$858.00
Buy Now And Earn 858 Reward Points!
GENERAL
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPSâ„¢ Bypass Technology
Energy Star Qualified: Yes
Active PFC Compatibility: Yes
INPUT
Nominal Input Voltage (Vac): 230
Input Voltage Range (Vac): 151 ~ 301
Input Frequency (Hz): 50 ± 3 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current (A): 10
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: AU/IEC C14
Power Cord Length (ft.): 6/6
Power Cord Length (m.): 1.83/1.83
OUTPUT
Capacity (VA): 1500
Capacity (Watts): 1350
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) (Vac): 230 ± 5%
On Battery Frequency (Hz): 50 ± 1% 60 ± 1%
Automatic Voltage Regulation (AVR): Double Boost, Single Buck
Overload Protection: Internal Current Limiting
Outlet(s) – Total: 8
Outlet Type: IEC C13 x8
Outlet(s) - Battery & Surge Protected: 8
Outlet(s) – Critical Load (CL): 4
Outlet(s) –Non-Critical Load (NCL): 4
Typical Transfer Time (ms): 4
BATTERY
Runtime at Half Load (min): 17
Runtime
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPSâ„¢ Bypass Technology
Energy Star Qualified: Yes
Active PFC Compatibility: Yes
INPUT
Nominal Input Voltage (Vac): 230
Input Voltage Range (Vac): 151 ~ 301
Input Frequency (Hz): 50 ± 3 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current (A): 10
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: AU/IEC C14
Power Cord Length (ft.): 6/6
Power Cord Length (m.): 1.83/1.83
OUTPUT
Capacity (VA): 1500
Capacity (Watts): 1350
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) (Vac): 230 ± 5%
On Battery Frequency (Hz): 50 ± 1% 60 ± 1%
Automatic Voltage Regulation (AVR): Double Boost, Single Buck
Overload Protection: Internal Current Limiting
Outlet(s) – Total: 8
Outlet Type: IEC C13 x8
Outlet(s) - Battery & Surge Protected: 8
Outlet(s) – Critical Load (CL): 4
Outlet(s) –Non-Critical Load (NCL): 4
Typical Transfer Time (ms): 4
BATTERY
Runtime at Half Load (min): 17
Runtime
| EAN | 4712364143816 |
|---|---|
| MPN | PR1500ELCD |
| Brand | CyberPower (CyberPower Systems) |
| Model | PR1500ELCD |
| Notes | Includes detachable LCD panel, power cord, USB cable, serial cable, EPO cable and user manual (varies by region) Reported firmware/operation notes: internal battery aging detection via impedance measurement; reported inability to calibrate below 20% load in one review |
| Series | Professional Series Smart App Sinewave |
| Battery | Capacity: 17 Ah (each) Configuration: Two 12V batteries connected in series Hot-swappable: true Charging Modes: Fast (approx. 3 hours), Economy (approx. 8 hours) User-replaceable: true Charging Power Consumption: { "Fast": "approx. 160 W", "Economy": "approx. 60 W" } Battery Pack Model (not supplied): RBP0023 |
| Category | Power and Rack Equipment > Power Equipment |
| Features | Active PFC compatible Automatic Voltage Regulation (AVR) Pure sine wave output Hot-swappable batteries User-replaceable batteries Detachable LCD panel Emergency Power Off (EPO) Overload protection Auto-restart / Auto-charge Energy saving / GreenPower UPS technology (reported) |
| Physical | Color: Black Cooling: 80 x 80 x 25 mm fan (24 V) — reported to activate on battery/AVR/boost charge/overheat Chassis Material: Steel case (reported) Dimensions (W x H x D): 170 x 221 x 432 mm |
| Topology | Line-interactive |
| Description | The CyberPower PR1500ELCD is a tower, line-interactive UPS delivering 1500 VA / 1350 W with pure sine wave output and 3-stage Automatic Voltage Regulation (AVR). Designed for servers, workstations, network and telecom equipment, it provides surge/EMI/RFI protection, eight IEC outlets (critical and non-critical groups), hot-swappable/user-replaceable batteries, a detachable multifunction LCD panel, USB and RS-232 connectivity, and optional SNMP/HTTP remote management via an expansion card. PowerPanel management software enables local or unattended shutdowns, monitoring and event logging. |
| Form Factor | Tower (mini-tower) |
| Outlet Type | IEC (8) |
| Input Voltage | 230 V AC (EU variants referenced) |
| Product Title | CyberPower PR1500ELCD 1500VA (1350W) Line-Interactive Tower UPS with Detachable LCD |
| Outlets (count) | 8 |
| Output Waveform | Pure Sine Wave |
| Power Rating VA | 1500 VA |
| Reported Runtime | 100 W: approx. 180 minutes 200 W: approx. 90 minutes 300 W: approx. 50 minutes Full Load (reported): 4 minutes Half Load (reported): 17 minutes |
| Country of Origin | China |
| Ports & Interfaces | USB (HID) RS-232 (DB-9) EPO (Emergency Power Off) port SNMP expansion slot (optional remote management card; supports RMCARD202 and RMCARD203) RJ45 LAN protection (reported) |
| Power Rating Watts | 1350 W |
| Optional / Expansion | SNMP/HTTP remote management cards (RMCARD202, RMCARD203) External replacement battery packs (RBP0023 referenced as battery pack model) |
| Management & Software | LCD: Detachable multifunction LCD panel (2-line, 5 buttons) with ~1.5 m cable Software: PowerPanel Business / PowerPanel Management software (Windows, Linux) Local Management: USB and serial connectivity Remote Management: Optional SNMP/HTTP card (RMCARD series) |
| Warranty & Guarantees | Three-year limited warranty (reported) and $375,000 Connected Equipment Guarantee (reported) |
| Protections & Filtering | Surge protection Spike protection EMI and RFI filtration Lightning/spike protection Critical and non-critical outlet grouping |
| Compatibility & Use Cases | Servers Workstations Network devices Telecom equipment Storage / NAS VOIP / mission-critical applications |
| Automatic Voltage Regulation (AVR) | 3-stage AVR (multi-step regulation; reported transfer to battery below 160 V and above 280 V; increased-voltage step up to 250 V) |
CyberPower PRO series 1500VA / 1350W (10A) Tower UPS with LCD -(PR1500ELCD)- 3 yrs Adv. Rep & 2 yrs on Int. Battery
