STARTECH USB-C MULTIPORT ADAPTER, 4K HDMI/VGA MINI LAPTOP TRAVEL DOCK 3 YR DKT31CVHPD3
USB-C MINI DOCKING STATION: USB-C to HDMI 2.0b (4K 60Hz) or VGA 1080p for connectivity to a monitor or display, 100W Power Delivery Pass-Through, 3-Port USB 3.2 (10Gbps) hub (2x USB-A, 1x USB-C); Gigabit Ethernet Port (PXE boot/WoL)
CABLE MANAGEMENT: Thoughtful hideaway tethered design prevents cable clutter; The attached 1ft / 32cm long cable reduces strain on the USB-C laptop connector, while shorter cables common in other adapters create strain on the laptop USB-C connector
RELIABLE PERFORMANCE: Prevent device dropouts, video flickering, and power overdraw common in other mini docks; Up to 100W PD Pass-Through with 84W for the laptop while reserving 16W for the adapter and attached devices
UNIVERSAL COMPATIBILITY: Works with all major operating systems (Windows, ChromeOS, macOS, Linux), and all hardware platforms including Intel, Apple M1 / M2, and AMD; Works with USB-C, USB4, Thunderbolt 3 & 4
CONNECTIVITY TOOLS: Includes Network MAC Address Pass-Through, WiFi Auto Switching, USB Event Monitoring, and Windows Layout Utilities for IT Pro's and IT help-desk support teams; These tools are not included with docks from consumer brands
Warranty Information
Warranty
3 Years
Package Quantity
1
Ports
3
Connector(s)
External Ports
1 - HDMI (19 pin)
1 - VGA (15 pin, High Density D-Sub)
2 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps)
1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
1 - USB Type-C (24 pin) USB Power Delivery Only
1 - RJ-45
Host Connectors
1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
Environmental
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-20°C to 55°C (-4°F to 158°F)
Humidity
0% to 85% (non-condensing)
Hardware
4K Support
Yes
Fast-Charge Port(s)
No
Displays Supported
1
Interface
USB 3.2 Gen 2 (10 Gbps)
Bus Type
USB-C
Industry Standards
HDMI 2.0b
DisplayPort 1.4
Chipset ID
Realtek - RTD2142
Realtek - RTL8153B
VIA - VL822-Q8
VIA - VL103
Indicators
LED Indicators
1 - Network Link Speed - Green (Network Operating at 1Gbps or 100Mbps), Off (Network Operating at 10Mbps or Lower)
1 - Network Link Status - Solid Amber (Link Detected), Flashing Amber (Link Activity), Off (No Link Detected)
Packaging Information
Package Length
6.7 in [17.0 cm]
Package Width
5.6 in [14.2 cm]
Package Height
1.2 in [3.0 cm]
Shipping (Package) Weight
5.4 oz [154.0 g]
Performance
Maximum Data Transfer Rate
10Gbps
Maximum Digital Resolutions
HDMI: 4K (4096 × 2160) 60Hz
VGA: 1080p (1920 x 1200/1080) 60Hz
Type and Rate
USB 3.2 Gen 2 - 10 Gbit/s
UASP Support
Yes
Compatible Networks
10/100/1000 Mbps
PXE
Yes
Full Duplex Support
Yes
General Specifications
Maximum Laptop Charging: 84W
Physical Characteristics
Color
Space Gray
Product Length
4.9 in [12.4 cm]
Product Width
2.5 in [6.4 cm]
Product Height
1.0 in [2.5 cm]
Weight of Product
4.6 oz [130.0 g]
Material
Plastic
Cable Length
12.6 in [32 cm]
Power
Power Source
Bus Powered and Host USB-C Power Adapter
Power Delivery
100W
Power Consumption (In Watts)
16W
Software
OS Compatibility
Windows® 7, 8, 8.1, 10, 11
macOS 10.15, 11.0, 12.0, 13.0
Android™
Linux® Ubuntu 18.04, 20.04
ChromeOS™
Special Notes / Requirements
System and Cable Requirements
A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 3.0 and DP alt mode).
Note
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that the host's USB-C port supports USB Power Delivery and DP alt mode.
If the USB-C Host does not support USB Power Delivery, the PD Power Port will not supply power to the USB-C Host.
USB 3.2 Gen 2 (10Gbps) is also known as SuperSpeed USB 10Gbps, and USB 3.1 Gen 2 (10Gbps).
The host laptop may have specific charging requirements. For example, if the laptop requires exactly 60W of power and an adapter consumes some of the 60W, your laptop might not recognize that it is getting enough power. For information pertaining to Power Delivery capability, refer to the technical documents included with the host laptop.
What's in the Box
Included in Package
1 - USB-C Multiport Adapter
1 - Quick-Start Guide
