Eaton Powerware 5SC 750VA / 525W Line Interactive Sine Wave Mini Tower Ups. Network Based Using Ipp As A Proxy. 5SC750i
SKU
157455
Brand
MPN
5SC750i
Warranty
Standard Manufacturer's Warranty
$668.00
Buy Now And Earn 668 Reward Points!
Eaton 5SC UPS provides line-interactive, affordable and reliable protection for small business servers. Complementing our range of industry leading UPSs, the 5SC includes an LCD interface for real-time status and measurements, and provides sinewave output for compatibility with today’s most sensitive IT equipment.
| MPN | 5SC750I |
|---|---|
| SKU | 5SC750I |
| UPC | 743172045157 |
| Brand | Eaton |
| Color | Black |
| Model | 5SC750I |
| Notes | Tower UPS designed for small servers, networking and storage. Integrates with Eaton power management software for monitoring and controlled shutdowns. |
| Weight | 10.4 kg (approx.) |
| Wattage | 525 W |
| Category | Power and Rack Equipment |
| Topology | Line-interactive |
| Enclosure | Black |
| VA Rating | 750 VA |
| Description | The Eaton 5SC 750VA (525W) is a compact, line-interactive tower UPS that protects servers, networking and storage equipment from power outages and voltage fluctuations. It provides automatic voltage regulation (AVR) and delivers a clean sine-wave output. The unit features an LCD for real-time status and measurements, USB (HID) and RS-232 communication ports, Advanced Battery Management (ABM) to extend battery life, and six C13 output receptacles. User-replaceable, maintenance-free lead-acid batteries provide runtime of approximately 5 minutes at full load and about 12.5 minutes at half load. The 5SC750I fully integrates with Eaton power management software for automated shutdowns and monitoring. |
| Form Factor | Tower (free-standing) |
| Noise level | <40 dB at 1 m |
| Part Number | TE-2880665 |
| Battery type | Lead-acid, maintenance-free (user replaceable) |
| Input phases | 1 |
| Sub-Category | Power Equipment |
| Output phases | 1 |
| Phase (input) | Single-phase |
| Product Title | Eaton 5SC 750VA (525W) Line-Interactive UPS, 230V, 6x C13, LCD (5SC750I) |
| Battery rating | 12 V / 7 Ah |
| Phase (output) | Single-phase |
| User interface | LCD display |
| Output waveform | Sine wave |
| Battery quantity | 2 |
| Input connection | C14 (IEC) |
| Output frequency | 50/60 Hz |
| Nominal frequency | 50-60 Hz |
| Rack mounting kit | Not included (tower model) |
| Relative humidity | 0-90% non-condensing |
| Battery management | ABM (Advanced Battery Management) and constant-voltage charging (user selectable), automatic battery test, deep-discharge protection |
| Output receptacles | 6 x C13 (IEC) |
| BTU rating (online) | 106 |
| Battery replaceable | Yes (user replaceable) |
| Communication ports | USB (HID compliant), Serial (RS-232) |
| Input voltage - max | 276 V |
| Input voltage - min | 184 V |
| Input voltage range | 184 - 276 V |
| Output Power Factor | 0.7 |
| Included accessories | USB cable, Serial cable, (2) IEC-IEC power cables, Quickstart guide, Safety instructions |
| Output voltage range | 230 V (+6% / -10%) |
| Runtime at full load | Approximately 5 minutes |
| Runtime at half load | Approximately 12.5 minutes |
| Input frequency range | 45-55 Hz (50 Hz system), 55-65 Hz (60 Hz system) |
| Input nominal voltage | 230 V (default) — selectable 220/230/240 V |
| Operating temperature | 0-40°C (manufacturer materials list non-condensing ranges; referenced as 0-90% non-condensing humidity range) |
| Auto shutdown function | Yes (software-controlled shutdown via communication ports) |
| Dimensions (H x W x D) | 210 mm x 340 mm x 150 mm |
| Efficiency at max load | 96% |
| Output nominal voltage | 230 V (default) — selectable 220/230/240 V |
| Software compatibility | Eaton Intelligent Power Protector / Eaton Intelligent Power Manager |
| Altitude (max operating) | 2000 m |
| Power consumption (idle) | 31 W |
| Certifications / Compliance | IEC/EN 62040-1 IEC/EN 62040-2 UL 1778 CE EAC cTUVus TUV |
| Extended battery capability | No |
| Output frequency range (secondary) | 50 - 60 Hz |
EATON Powerware 5SC 750VA / 525W Line Interactive Sine Wave Mini Tower UPS. Network based using IPP as a proxy.
