StarTech.com Wall Mount for TV, Flat Panel Display, Curved Screen Display - Black, Silver - Spring-assisted height adjustable TV wall mount range 12.6in/32cm; Extendable arm range 23.4in/59.5cm - Tilting/swivel/full motion for 23-55in TVs; 75x75 to 40 FHA
StarTech.com Wall Mount for TV, Flat Panel Display, Curved Screen Display - Black, Silver - Spring-assisted height adjustable TV wall mount range 12.6in/32cm; Extendable arm range 23.4in/59.5cm - Tilting/swivel/full motion for 23-55in TVs; 75x75 to 400x400 VESA TV wall mount patterns; 66lb/30kg capacity - TV mounting bracket ships assembled
The steel and aluminum construction of this VESA TV Wall Mount supports TVs from 23" to 55" and up to 66lb (30kg). The arm assembly provides smooth one-touch height adjustment thanks to its spring-loaded mechanism that acts as a counterbalance. The VESA plate supports mounting patterns of 75x75 to 400x400.Versatile TV Mounting
Securely mount a flat or curved-screen TV or digital signage in a convenient location for viewing by visitors, clients, and employees. This TV wall mount is ideal for lobbies, boardrooms, and manufacturing facilities. The lateral range of 3.54 ft (1.08m) is ideal for corner mounting. The jointed arm folds on itself and creates a slim profile from the wall of just 2.2in (5.8cm) for limited space installations. The minimum TV weight is 17.6lb (8kg). M5/M6/M8 Screws of various lengths and an assortment of washers and spacers enhance TV mounting compatibility. Mount into wood-stud or concrete walls, using the included hardware.
Supported VESA mounting patterns: 75x75,100x100, 200x100, 200x200, 300x300, 400x200, and 400x400.
Full-Motion Adjustment
The VESA plate swivels +90 / -90 degrees, tilts +8 / -15 degrees, and rotates +3 / -3 degrees. Customize the viewing experience and comfort with these full-motion capabilities. The one-touch spring-assisted mechanism facilitates effortless height adjustments, with a range of up to 12.6in (32cm).
The arm assembly extends up to 23.4 in (59.5 cm) from the wall to accommodate different viewing positions.
Durable Construction
The robust steel and aluminum design safely and securely supports the TV. The arm assembly features built-in cable management and a wall mount cover for a an organized and visually appealing installation.
The height adjustable TV wall mount is backed for two years, including free lifetime 24/5 multi-lingual technical assistance.
- HEIGHT ADJUSTABLE TV WALL MOUNT: Spring-assisted height adjustable range 12.6in (32cm); Articulating wall mount TV bracket supports TVs from 23 to 55in; VESA patterns 75x75 up to 400x400; Max weight 66lb (30kg); Steel/aluminum frame with silver finish
- ONE-TOUCH MOTION: Full motion TV wall mount features a spring mechanism that acts as counterbalance for effortless height adjustments; VESA plate features +/-90° swivel, +8/-15° tilt, and +/-3° rotation to customize the viewing angle; Toolless adjustment
- RANGE OF MOTION: Low profile VESA TV wall mount with jointed arm assembly supports +/-90° swivel and folds to just 2.2in (5.8cm) from the wall; Max arm extension 23.4in (59.5cm); Lateral range of 3.9ft (1.19m) ideal for corner mounting maximizing space
- COMPATIBILITY: TV mounting bracket supports TVs up to 55" from LG, Samsung, Sony, Hisense, Sharp, and other TVs; Compatible VESA patterns: 75x75, 100x100, 200x100, 200x200, 300x300, 400x200, and 400x400; Spacers and various M5/M6/M8 screws included
- QUICK AND CLEAN INSTALLATION: Swivel TV wall mount ships assembled for quick deployment; Keyhole mounting holes on the wall plate facilitate simplified installation; Wood stud and concrete wall mounting hardware included; Built-in cable management
| Application/Usage | Lobby |
| Wall | |
| Board Room |
| Product Type | Wall Mount |
| Manufacturer Part Number | FHA-TV-WALL-MOUNT |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | Wall Mount |
| Brand Name | StarTech.com |
| Finishing | Silver |
| Weight (Approximate) | 5.99 kg |
| Length | 59.4 cm |
| Height | 45 cm |
| Width | 45 cm |
| VESA Mount Compatible | Yes |
| Mounting Pattern | 200 x 200 |
| 300 x 300 | |
| 400 x 400 | |
| 75 x 75 | |
| 400 x 200 | |
| 200 x 100 | |
| 100 x 100 | |
| Product Color | Silver |
| Black | |
| Product Material | Steel |
| Aluminium |
| Device Supported | Flat Panel Display |
| TV | |
| Curved Screen Display | |
| Features | Cable Management |
| Articulating | |
| Adjustable | |
| 8°/-15° Tilt | |
| Tool-less Adjustment | |
| +/- 90° Swivel | |
| +/- 3° Rotation | |
| Durable | |
| Full Motion | |
| 180° Swivel | |
| Maximum Load Capacity | 30 kg |
| Minimum Screen Size Supported | 58.4 cm |
| Maximum Screen Size Supported | 139.7 cm (55") |
| Number of Displays Supported | 1 |
| Mount Profile | Low Profile |
| Minimum Load Capacity | 8 kg |
| Height Adjustable | Yes |
