Field Assembly Fibre Optical Singlemode Connector | Sc Connector | Bag Of 6 015.002.0100
SKU
244415
Brand
MPN
015.002.0100
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$32.00
Buy Now And Earn 32 Reward Points!
Field Assembly Fibre Optical Singlemode Connector | SC Connector | Bag of 6
Field assembly connector or fast connector is an innovative field installable optical fibre connector designed for simple and fast field termination of single fibers. Without using additional assembling tools, field assembly connector can be quickly and easily connected to the drop cable and indoor cable, which saves a lot of required termination time. It is specially designed with the patented mechanical splice body that includes a factory-mounted fibre stub and a pre-polished ceramic ferrule. Field assembly connectors enable fast and on-site installation of 250µm, 900µm, 3.0mm and 1.6mm x 2.0mm, 2.0mm x 3.0mm cable type connectors even when the user has no access to power. The whole installation process only takes about 2 minutes which greatly improves the working efficiency.
FEATURES
Field-installable, cost-effective, user-friendly
No requirement for epoxy and polishing
Quick and easy fibre termination in the field
No need for fusion splicer, power source and tool for pressure
Visual indication of proper termination
Suitable for all standard OS1 and OS2 fibre cables
Performance
Item
Performance
Insertion Loss
Average ≤ 0.2dB，Max ≤ 0.4dB
Return Loss
PC：≥ 45dB，APC：≥ 55dB
One-time Assembly Rate
≥ 97%
Assembly Repeatability
More than 5 times
Average Assembly Time
≤3 minutes
Life-time
≥ 30years
Tensile Strength
≥ 30N（2×3)Bow-type drop cable
Operation Temperature
-40℃ ～ +85℃
WARRANTY
1-year warranty.
WHY 4CABLING?
Australia’s leading importer & wholesaler of 19” server racks, copper, ethernet cable, fibre optic leads & structured networking products
ISO 9001, NSW Govt. & GITC (QLD Govt.) approved supplier
Secure online shopping 24/7
A loyal customer base of 100k+ who trust us for their data & electrical needs
Over 3000 quality products in stock ready to go
All products are approved as per local Australian standards
Warranty & peace of mind return policy
Lightning fast delivery nationwide
Expert advice
Proudly 100% Australian owned & operated
Field assembly connector or fast connector is an innovative field installable optical fibre connector designed for simple and fast field termination of single fibers. Without using additional assembling tools, field assembly connector can be quickly and easily connected to the drop cable and indoor cable, which saves a lot of required termination time. It is specially designed with the patented mechanical splice body that includes a factory-mounted fibre stub and a pre-polished ceramic ferrule. Field assembly connectors enable fast and on-site installation of 250µm, 900µm, 3.0mm and 1.6mm x 2.0mm, 2.0mm x 3.0mm cable type connectors even when the user has no access to power. The whole installation process only takes about 2 minutes which greatly improves the working efficiency.
FEATURES
Field-installable, cost-effective, user-friendly
No requirement for epoxy and polishing
Quick and easy fibre termination in the field
No need for fusion splicer, power source and tool for pressure
Visual indication of proper termination
Suitable for all standard OS1 and OS2 fibre cables
Performance
Item
Performance
Insertion Loss
Average ≤ 0.2dB，Max ≤ 0.4dB
Return Loss
PC：≥ 45dB，APC：≥ 55dB
One-time Assembly Rate
≥ 97%
Assembly Repeatability
More than 5 times
Average Assembly Time
≤3 minutes
Life-time
≥ 30years
Tensile Strength
≥ 30N（2×3)Bow-type drop cable
Operation Temperature
-40℃ ～ +85℃
WARRANTY
1-year warranty.
