Ip-Com (G1016D V6.0) 16-Port Gigabit Unmanaged Switch, 6kv Lightning Protection G1016D
SKU
388507
Brand
MPN
G1016D
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$104.00
Buy Now And Earn 104 Reward Points!
IP-COM G1016D 16-Port Gigabit Unmanaged Switch
• 16*10/100/1000 Mbps Ethernet ports
• 8K MAC address, MAC auto Learning & Auto Aging
• IEEE 802.3x full duplex flow control, and backpressure half duplex flow control
• 32 Gbps switching fabric for non-blocking line-speed forwarding
• LED indicators for indicating working status and troubleshooting
• 16 ports all with 6kV lightning protection
• Desktop or rack mounting
• Plug & Plug
• 16*10/100/1000 Mbps Ethernet ports
• 8K MAC address, MAC auto Learning & Auto Aging
• IEEE 802.3x full duplex flow control, and backpressure half duplex flow control
• 32 Gbps switching fabric for non-blocking line-speed forwarding
• LED indicators for indicating working status and troubleshooting
• 16 ports all with 6kV lightning protection
• Desktop or rack mounting
• Plug & Plug
| SKU | G1016D |
|---|---|
| Brand | IP-COM |
| Model | G1016D |
| Cooling | Fanless |
| Version | v8.0 |
| Category | Networking |
| Features | Plug and play Auto MDI/MDIX Auto negotiation MAC auto learning & aging LED status indicators Built-in lightning protection Full-steel, fanless design |
| Condition | New |
| SFP Ports | 0 |
| USB Ports | 0 |
| Management | Unmanaged |
| Description | The IP-COM G1016D is a 16-port unmanaged Gigabit Ethernet switch designed for reliable wired networking and video surveillance in offices, SMBs, schools, factories and community deployments. It provides 16 x 10/100/1000 Mbps auto-negotiation RJ45 ports with Auto MDI/MDIX, non-blocking 32 Gbps switching fabric and an 8K MAC address table for wire-speed forwarding. The full-steel, fanless 13-inch design supports desktop, wall and rack mounting. Built-in power supply and professional lightning protection (ports and power) increase stability in harsh environments. Plug-and-play operation, IEEE 802.3/802.3u/802.3ab/802.3x compliance and IEEE 802.3x full-duplex flow control/backpressure half-duplex control make it easy to deploy and maintain. |
| Power Input | 100~240V AC, 50/60Hz (built-in power supply) |
| Applications | Video surveillance Offices Work groups SMBs/SMEs Communities Factories Schools |
| Buffer/Cache | 4 Mb large buffer (reported) |
| Flow Control | IEEE 802.3x full-duplex flow control; backpressure for half-duplex |
| Manufacturer | IP-COM |
| Product Type | Unmanaged Switch |
| Sub-Category | Switches and Hubs |
| Auto MDI/MDIX | Yes |
| Physical Size | 13-inch body (mountable desktop/wall/rack) |
| Product Title | IP-COM G1016D 16-Port Gigabit Unmanaged Switch (v8.0) |
| LED Indicators | Yes |
| NDAA Compliance | No |
| Number of Ports | 16 |
| Auto-Negotiation | Yes |
| Housing Material | Full steel housing |
| Mounting Options | Desktop Wall Rack |
| MAC Address Table | 8K |
| Compliance / Notes | Data reported from manufacturer/resellers; refer to actual product for final specifications. |
| Port Specification | 16 x 10/100/1000 Mbps auto-negotiation RJ45 ports |
| Switching Capacity | 32 Gbps |
| Backplane Bandwidth | 32 Gbps (non-blocking) |
| Warranty (reported) | 1 year (reseller reported); 3 year factory warranty (reported on one source) |
| Lightning Protection | Ports: 6 kV common mode (IV-class) Power: 6 kV common mode; 4 kV differential mode (reported) |
| Standards and Protocols | IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x |
| Power over Ethernet (PoE) | No |
| Shipping Weight (reported) | 1.30 kg |
| Weight (product, reported) | 0.5 kg |
| Shipping Dimensions (reported) | 6.00 cm x 31.00 cm x 19.51 cm |
| Max Full Duplex Transmission Rate | 2000 Mbps (as reported) |
IP-COM (G1016D v6.0) 16-Port Gigabit Unmanaged Switch, 6kv lightning protection
