Ip-Com (G1024D) 24-Port Gigabit Unmanaged Switch, 6kv Lightning Protection G1024D
SKU
388508
Brand
MPN
G1024D
Warranty
Standard Manufacturer's Warranty
$127.00
Buy Now And Earn 127 Reward Points!
IP-COM G1024 24-Port Gigabit Unmanaged Switch
• Compliant with IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab standards
• 24*10/100/1000 Mbps Ethernet ports
• 8K MAC address and MAC auto Learning & Auto Aging
• IEEE 802.3x full duplex flow control, and backpressure half duplex flow control
• 48 Gbps switching fabric for non-blocking line-speed forwarding
• LED indicators for indicating working status and troubleshooting
• Built-in power supply system with 6 kV common mode and 4 kV differential mode lightning protection
• 6kV lightning protection
• Plug and play
• Compliant with IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab standards
• 24*10/100/1000 Mbps Ethernet ports
• 8K MAC address and MAC auto Learning & Auto Aging
• IEEE 802.3x full duplex flow control, and backpressure half duplex flow control
• 48 Gbps switching fabric for non-blocking line-speed forwarding
• LED indicators for indicating working status and troubleshooting
• Built-in power supply system with 6 kV common mode and 4 kV differential mode lightning protection
• 6kV lightning protection
• Plug and play
| PoE | No (Non-PoE) |
|---|---|
| SKU | G1024D |
| Brand | IP-COM |
| Model | G1024D |
| Notes | Plug-and-play unmanaged design; no user configuration required. |
| Power | AC Input: 100–240V AC, 50/60 Hz Power Supply: Built-in Power Consumption: 12W |
| Cooling | Fanless (silent) |
| Category | Networking |
| Warranty | 1 year |
| Condition | New |
| Dimensions | 11.69 x 7.01 x 1.73 inches (as specified) |
| Port Speed | 10/100/1000 Mbps |
| Buffer Size | 4 Mb |
| Description | The IP-COM G1024D is a 24-port gigabit unmanaged switch offering full wire-speed, non-blocking forwarding for reliable high-speed wired networks. Housed in a metal, fanless chassis, it supports desktop, wall and 1U rack mounting and is optimized for video surveillance, offices, workgroups and SMB deployments. The switch provides 24 x 10/100/1000 Mbps auto-negotiation RJ45 ports with Auto MDI/MDIX, an 8K MAC table, 4 Mb packet buffer, IEEE 802.3x full-duplex and backpressure half-duplex flow control, and a 48 Gbps switching fabric. Built-in power supply (100–240VAC) and integrated lightning protection (ports and power) help protect operation in harsh environments. Compact, plug-and-play operation with LED status indicators makes it easy to deploy as a reliable access/aggregation switch for IP cameras and wired networks. |
| Form Factor | Rackmount Desktop Wall-mountable |
| Flow Control | IEEE 802.3x full-duplex; backpressure half-duplex |
| Product Type | Unmanaged Switch |
| Sub-Category | Switches and Hubs |
| Optimized For | IP camera / video surveillance Offices SMBs Workgroups Hotels Schools Factories Communities |
| Port Features | Auto-negotiation Auto MDI/MDIX |
| Primary Ports | 24 x RJ45 |
| Product Title | IP-COM G1024D 24-Port Gigabit Unmanaged Switch (Rack/Desktop) |
| LED Indicators | 24 x Link/Act indicators, 1 x Power indicator |
| Model Revision | v9.0 |
| NDAA Compliance | No |
| Number of Ports | 24 |
| Chassis Material | All-steel / metal housing |
| Storage Humidity | 5% to 90% non-condensing |
| MAC Address Table | 8K (8000 entries) |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Temperature | -40°C to 70°C |
| Standards Compliance | IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x |
| Operating Temperature | 0°C to 45°C |
| Lightning / Surge Protection | Built-in lightning protection (ports: 6 kV common mode; differential mode up to 4 kV; power supply protection up to 6 kV as specified) |
| Switching Fabric / Backplane | 48 Gbps |
| Forwarding / Switching Method | Store-and-forward, non-blocking wire-speed forwarding |
| Maximum Full-Duplex Transmission Rate (per port) | 2000 Mbps (as specified) |
IP-COM (G1024D) 24-Port Gigabit Unmanaged Switch, 6kv lightning protection
