Ip-Com (G1024D) 24-Port Gigabit Unmanaged Switch, 6kv Lightning Protection G1024D
SKU
388508
Brand
MPN
G1024D
Warranty
Standard Manufacturer's Warranty
$127.00
Buy Now And Earn 127 Reward Points!
IP-COM G1024 24-Port Gigabit Unmanaged Switch
• Compliant with IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab standards
• 24*10/100/1000 Mbps Ethernet ports
• 8K MAC address and MAC auto Learning & Auto Aging
• IEEE 802.3x full duplex flow control, and backpressure half duplex flow control
• 48 Gbps switching fabric for non-blocking line-speed forwarding
• LED indicators for indicating working status and troubleshooting
• Built-in power supply system with 6 kV common mode and 4 kV differential mode lightning protection
• 6kV lightning protection
• Plug and play
• Compliant with IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab standards
• 24*10/100/1000 Mbps Ethernet ports
• 8K MAC address and MAC auto Learning & Auto Aging
• IEEE 802.3x full duplex flow control, and backpressure half duplex flow control
• 48 Gbps switching fabric for non-blocking line-speed forwarding
• LED indicators for indicating working status and troubleshooting
• Built-in power supply system with 6 kV common mode and 4 kV differential mode lightning protection
• 6kV lightning protection
• Plug and play
| Standard&Protocol | IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3ab |
| Forwarding Speed | 10Mbps : 14880pps 100Mbps : 148800pps 1000Mbps : 1488000pps |
| Transmission Media | 10BASE-T: UTP category 3, 4, 5 cable 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable |
| Port | 24*10/100/1000Mbps auto-negotiation RJ 45 ports (Auto MDI/MDIX) |
| LED Indication | 24*10/100/1000Mbps Link/Act indicator,1*power indicator |
| Dimensions | 297mm×178mm×44mm |
| Switch Feature | Store-and-Forward MAC auto Learning & Auto Aging 8K MAC 48Gbps Backpanel bandwidth |
| Lighting Proof | lightning protection 6KV for power supply,6KV for all ports |
| Power Input | 100~240V AC，50/60Hz |
| Operating Environment | Temperature:0℃~45℃ Humidity:10%~90% non-condensing |
| Storage Environment | Temperature:-40℃~70℃ Humidity:5%~90% non-condensing |
IP-COM (G1024D) 24-Port Gigabit Unmanaged Switch, 6kv lightning protection
