Ip-Com (G5310P-8-150W) 10-port L3 Cloud Managed PoE Switch G5310P-8-150W
SKU
380958
Brand
MPN
G5310P-8-150W
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$296.00
Buy Now And Earn 296 Reward Points!
IP-COM G5310P-8-150W 10-port L3 Cloud Managed PoE Switch
| PoE | Polarity: 1,2,4,5 + ; 3,6,7,8 - Standard: IEEE 802.3af/at Max Per Port: Up to 30 W (802.3at) Ports Supported: Ports 1-8 Total PoE Budget: 130 W PoE Management/Protection: Port PoE configuration and priority; PoE over-temperature protection; PoE scheduled management; PSE short-circuit, overload and overvoltage protection; PD detection/status reporting |
|---|---|
| SKU | G5310P-8-150W |
| Brand | IP-COM |
| Model | G5310P-8-150W |
| Notes | Specifications compiled from multiple manufacturer/distributor sources. Some listings contain conflicting PoE figures; the consolidated total PoE budget above is taken from the majority of detailed technical listings for this SKU. |
| Physical | Weight: 2.489 kg Dimensions (W x D x H): 294 mm x 179.6 mm x 44 mm (11.57" x 7.07" x 1.73") |
| Standards | IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3ad IEEE 802.3z IEEE 802.3x IEEE 802.1p IEEE 802.1q IEEE 802.1w IEEE 802.1d IEEE 802.1s IEEE 802.3af IEEE 802.3at |
| Description | IP-COM G5310P-8-150W is a Layer-3 cloud-manageable Gigabit PoE switch designed for medium to large enterprise and campus access/aggregation. It provides 9 Gigabit RJ45 ports (8 PoE + 1 non-PoE) plus one 1000Base-X SFP, supports IPv4 static routing, VLANs, IGMP snooping, QoS, ACLs, DHCP Server/Relay and DHCP Snooping, and can be managed locally or via IP-COM IMS cloud platform. The unit offers advanced security features (IP/MAC/ARP filtering, DoS defense, 802.1x/RADIUS), link aggregation (static and LACP), STP/RSTP/MSTP support, and professional 6 kV port and power lightning protection. Hardware highlights include a 16K MAC table, 12 Mbit buffer, 20 Gbps switching capacity (14.9 Mpps), IEEE 802.3af/at PoE (up to 30 W per port; 130 W total), and a compact 1U 13-inch form factor for rack mounting. |
| Performance | Buffer Memory: 12 Mbit Switching Method: Store-and-forward MAC Address Table: 16K (16,384 entries) Switching Capacity: 20 Gbps Packet Forwarding Rate: 14.9 Mpps |
| QoS and ACL | ACL: MAC ACL and IP ACL support QoS: SP (Strict Priority), SWRR, WRR; 802.1p and DSCP trust modes; up to 8 queue mappings |
| Environmental | Storage Humidity: 5% to 90% RH, non-condensing Operating Humidity: 10% to 90% RH, non-condensing Storage Temperature: -40°C to 70°C Operating Temperature: 0°C to 40°C |
| Product Title | IP-COM G5310P-8-150W L3 Cloud-Managed Gigabit PoE Switch (8 PoE + 1 LAN, 1 SFP, 130W) |
| Certifications | CE FCC RoHS CCC |
| LED Indicators | Per-port Link/Act or PoE LED; device Link/Link-Act mode LED; PoE mode LED; PoE Max LED; Power LED; SYS LED |
| Package Contents | G5310P-8-150W switch Power cord Rack-mount brackets (L-shaped / 19" mounting brackets) Mounting screws Footpads Quick installation guide / User's manual |
| Layer 3 & Routing | DHCP: DHCP Server/Relay support; DHCP Snooping; Option 82 policy Routing: IPv4 static routing; VLAN-based routing; static ARP |
| Security Features | IP address filtering MAC address filtering / unknown MAC discard ARP filtering / ARP receive limit DoS attack defense 802.1x authentication RADIUS authentication ACL access control |
| Port Configuration | SFP Ports: 1 x 1000Base-X SFP RJ45 Ports: 9 x 10/100/1000 Base-T (8 ports with PoE, 1 port data-only) |
| Power & Consumption | Input Voltage: 100-240V AC, 50/60 Hz Max PoE Output: 130 W Whole Switch Consumption: < 150 W |
| VLAN and L2 Features | LACP: Static aggregation and LACP dynamic aggregation VLAN: IEEE 802.1Q VLAN; supports VLAN Layer-3 interfaces; Access/Trunk/Hybrid port modes Spanning Tree: IEEE 802.1d STP, 802.1w RSTP, 802.1s MSTP; edge port; BPDU statistics Port Mirroring: N:1 port mirroring |
| Lightning & Protection | Dual 6 kV port and 6 kV power lightning protection; PSE short-circuit, overcurrent, overload, over-temperature and overvoltage protections |
| Alternate Model / Codes | ICIP-G5310P-8 TEG5310P-8-150W G5310P-8 |
| Management & Monitoring | Tools: Ping/Tracert detection; LAN device discovery and topology visualization (local visual management) Cloud Management: IP-COM IMS cloud platform support (remote config/maintenance, log reporting, fault detection) Local Management: Web GUI, Telnet, Console (when provided), SNMP v1/v2/v3 Upgrade & Backup: FTP / TFTP / HTTP upgrade; configuration import/export |
IP-COM (G5310P-8-150W) 10-port L3 Cloud Managed PoE Switch
