Startech Hdmi Signal Booster - 115 Ft - 1080p Hdboost
Features
- Discreet installation with a small form factor and no external power adapter
- Works at varying distances up to 115 ft. with a built-in equalization switch
- Maintain high-definition resolutions up to 1080p
- Supports 7.1 surround sound audio
- Mounting hardware included
Discreet installation
With its small form factor, the HDMI booster is easy to hide, for a discreet installation. You don’t need an external power adapter to operate the signal booster, and it includes mounting hardware, so installing it is hassle-free. By extending your video signal using standard HDMI cables, the HDMI booster is a cost-effective alternative to more expensive HDMI extension systems that require the installation of CAT5 or CAT6 cabling infrastructure.
Compatible with varying distances
The HDMI booster features an equalization switch with ten different levels. The equalization switch lets you adjust the amplification of your HDMI signal based on the distance of your cables, so that you can ensure your HDMI signal will be perfect even at distances up to 115 ft. (35 m). The booster is perfect for boardrooms, offices or classrooms that may require varying distances depending on the room size.
Maintains high-definition video signals
When extending HDMI over long distances using standard video cabling, higher resolutions can become unavailable. Using the HDMI signal booster ensures that you’ll still be able to depend on high-definition resolutions up to 1080p at 60Hz.
The HDBOOST is backed by a 2-year StarTech.com warranty and free lifetime technical support.
| Performance | |
| Audio Specifications | 7.1 surround Sound |
| Max Distance | 35 m / 115 ft |
| Maximum Cable Length | 35 m [114.8 ft] |
| Maximum Digital Resolutions | 1920 x 1080 at 60Hz |
| Supported Resolutions | 1920 x 1080, 1680 x 1050, 1600 x 900, 1440 x 900, 1360 x 768, 1280 x 800, 1280 x 768, 1280 ? 720 |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Product Height | 26.2 mm [1 in] |
| Product Length | 54.2 mm [2.1 in] |
| Product Weight | 72 g [2.5 oz] |
| Product Width | 42.2 mm [1.7 in] |
| Power | |
| Center Tip Polarity | Positive |
| Packaging Information | |
| Shipping (Package) Weight | 0.2 kg [0.4 lb] |
| Indicators | |
| LED Indicators | video source LED (blue) |
| power LED (blue) | |
| Hardware | |
| Rack-Mountable | Yes |
| Daisy-Chain | No |
| Cabling | HDMI |
| Audio | Yes |
| Environmental | |
| Storage Temperature | -10?C to 80?C (14?F to 176?F) |
| Operating Temperature | 0?C to 70?C (32?F to 158?F) |
| Humidity | 5% to 90% |
| Connector(s) | |
| Connector B | HDMI (19 pin) Female Output |
| Connector A | HDMI (19 pin) Female Input |
| Power | |
| Input Voltage | 100 ~ 240 AC |
| Output Current | 1 A |
| Output Voltage | 5 DC |
| Plug Type | N |
| Power Source | Not Included (not required for standard applications) |
| Special Notes / Requirements | |
| System and Cable Requirements | The HDMI cable connected to your video source must be longer or equal to the length of the cable connected to your display. |
| The maximum supported display cable length is 33 ft. (10m). | |
| The maximum supported video source cable length is 82 ft. (25m). | |
| What's in the Box | |
| Included in Package | HDMI signal booster |
| mounting brackets | |
| mounting screws | |
| screwdriver | |
This HDMI signal booster lets you increase the signal strength of your HDMI video source so you can connect an HDMI display up to 115 ft. (35 m) away, using standard HDMI cables. You can place the booster inline between two HDMI cables, up to 82 ft. in length at the video input, and up to 33 ft. in length at the video output.
Discreet installation
With its small form factor, the HDMI booster is easy to hide, for a discreet installation. You don?t need an external power adapter to operate the signal booster, and it includes mounting hardware, so installing it is hassle-free. By extending your video signal using standard HDMI cables, the HDMI booster is a cost-effective alternative to more expensive HDMI extension systems that require the installation of CAT5 or CAT6 cabling infrastructure.
Compatible with varying distances
The HDMI booster features an equalization switch with ten different levels. The equalization switch lets you adjust the amplification of your HDMI signal based on the distance of your cables, so that you can ensure your HDMI signal will be perfect even at distances up to 115 ft. (35 m). The booster is perfect for boardrooms, offices or classrooms that may require varying distances depending on the room size.
Maintains high-definition video signals
When extending HDMI over long distances using standard video cabling, higher resolutions can become unavailable. Using the HDMI signal booster ensures that you?ll still be able to depend on high-definition resolutions up to 1080p at 60Hz.
The HDBOOST is backed by a 2-year StarTech.com warranty and free lifetime technical support.
