The MEAN WELL HDR-60-24 is a 60W, 24V, 2.5A ultra-slim DIN rail power supply, ideal for space-saving installations in industrial control and home automation systems. Its narrow 52.5mm (3SU) width allows for efficient use of enclosure space. This reliable power supply features a universal AC input range of 85~264VAC and boasts a low no-load power consumption of less than 0.3W, contributing to energy efficiency. Designed with a plastic housing for enhanced safety against electric shock, it operates within a wide temperature range of -30°C to +70°C through free air convection. The HDR-60-24 is equipped with protections against short circuit, overload, and over voltage, ensuring the safety and longevity of your connected devices. It is a suitable replacement for MDR series power supplies.

Features
Ultra-slim design with a width of 52.5mm (3SU)
Universal AC input range: 85~264VAC (277VAC operational)
Low no-load power consumption: <0.3W
Plastic housing for enhanced safety
Cooling by free air convection
LED indicator for power on
Specifications
DC Output Voltage: 24V
Rated Output Current: 2.5A
Rated Output Power: 60W
Adjustable DC Output Voltage Range: 21.6~29V
AC Input Voltage Range: 85~264VAC (277VAC operational)
AC Input Current: 0.8A at 230VAC
Inrush Current: 60A at 230VAC
Efficiency: 90%
No Load Power Consumption: <0.3W
Over Voltage Protection: 30~36VDC, re-power to recover
Overload Protection: 105~160% rated output, recovers once fault removed
Working Temperature: -30°C to +70°C (refer to datasheet for derating)
Mounting: DIN rail TS-35/7.5 or TS-35/15
Dimensions: 52.5mm x 90mm x 54.5mm (W x H x D)
Weight: 0.19kg
Warranty

3-Year Limited Warranty
