Sophos 5G Module (for Xgs 116(w)/126(w)/136(w) Only) - All Regions HM5G1W00ZZPCAA
SKU
409225
Brand
MPN
HM5G1W00ZZPCAA
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,328.00
Buy Now And Earn 1328 Reward Points!
Sophos 5G module (for XGS 116(w)/126(w)/136(w) only) - All Regions
| SKU | HM5G1W00ZZPCAA |
|---|---|
| UPC | 5054074017919 |
| Brand | Sophos |
| Color | White |
| Model | 5G Module |
| Weight | 3 lb |
| Features | 5G connectivity Automatic fallback to LTE/3G Four external detachable antennas Supports multiple regional certifications |
| Condition | New |
| Interfaces | 4 x antenna ports |
| Description | The Sophos 5G Module (HM5G1W00ZZPCAA) is an internal wireless cellular modem designed to add 5G Sub-6 connectivity to Sophos XGS desktop firewalls (XGS 116w, 126w, 136w). It supports 5G NR, 5G Sub-6 GHz, 4G LTE (Cat-20), DC-HSPA+ and WCDMA, delivers up to 4.5 Gbps download and up to 660 Mbps upload, and provides automatic fallback to 4G/3G networks. The module uses four external detachable antennas for improved reception, meets multiple regional certification standards (FCC, PTCRB, GCF, JATE, IC, RED, TELEC), and must be installed with the firewall powered down (WWAN1/Cellular WAN configuration required after installation). |
| Form Factor | Internal |
| Antenna Type | External, detachable |
| Manufacturer | Sophos / Sophos Inc. |
| Product Line | Sophos |
| Product Type | Wireless cellular modem / Radio modem |
| Product Title | Sophos 5G Module (HM5G1W00ZZPCAA) — Internal Wireless Cellular Modem for XGS 116w/126w/136w |
| Supported Bands | 5G n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48/n66/n71/n77/n78/n79; LTE B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30f/B32/B34/B38/B39/B40/B41/B42/B43e/B46g/B48/B66/B71; DC-HSPA+ 1/2/4/5/6/8/9/19; WCDMA 1/2/4/5/6/8/9/19 |
| Antenna Quantity | 4 |
| Max Upload Speed | 660 Mbps |
| Compatible Models | Sophos XGS 116w Sophos XGS 116 Sophos XGS 126w Sophos XGS 126 Sophos XGS 136w Sophos XGS 136 |
| Fallback Networks | 4G LTE 3G |
| Packaged Quantity | 1 |
| Installation Notes | Module must be installed with the firewall powered down; after installation enable Cellular WAN and configure the WWAN1 interface (APN, username/password as required). The module cannot be replaced during operation. |
| Max Download Speed | 4.5 Gbps |
| Cellular Generation | 5G |
| Compliant Standards | FCC PTCRB GCF JATE IC RED TELEC |
| Connectivity Technology | Wireless |
| Manufacturer Part Number | HM5G1W00ZZPCAA |
| Supported Cellular Protocols | 5G NR 5G Sub-6 GHz 4G LTE (Cat-20) DC-HSPA+ WCDMA |
Sophos 5G module (for XGS 116(w)/126(w)/136(w) only) - All Regions
