HP 5406R 16SFP+ V3 ZL2 Switch Includes 2X 10GBE Sfp+ V3 ZL2MODULES, Managed, Life Wty JL095A
SKU
233294
Brand
MPN
JL095A
Warranty
Standard Manufacturer's Warranty
$20,953.00
Buy Now And Earn 20953 Reward Points!
HPE Aruba 5406R 16-port SFP+ (No PSU) v3 zl2 - Switch - Managed - 16 x 1 Gigabit / 10 Gigabit SFP+ - rack-mountable
| Ports | 16 x 1 Gigabit / 10 Gigabit SFP+ |
| Weight | 12.75 kg |
| Subtype | 10 Gigabit Ethernet |
| Capacity | IPv4 routing table entries: 10000 ? IPv6 routing table entries: 5000 |
| Features | Flow control, routing, DHCP support, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ support, IPv6 support, half duplex mode, full duplex mode, SNTP support, STP support, RSTP support, MSTP support, tunnelling, ACL support, QoS, MLD snooping, NSR, bandwidth control, STP Root Guard, UDLD, Rapid PVST+, IPv4 support, DHCP relay, Port Security, fan tray, DHCP client, Energy Efficient Ethernet, MIB, dynamic ARP protection, DHCP protection, dual firmware images, CoS, sFlow v5, GVRP, ToS, MACsec support |
| Device Type | Switch - 16 ports - Managed |
| Performance | Routing/switching capacity: 960 Gbps ? Throughput: up to 571.4 Mpps ? Switching fabric bandwidth: 1015 Gbps |
| Enclosure Type | Rack-mountable 4U |
| Routing Protocol | RIP-1, RIP-2, BGP, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, IGMPv3, OSPFv3, static IPv6 routing, MLDv2, MLD |
| Dimensions (WxDxH) | 44.45 cm x 45.09 cm x 17.53 cm |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX |
| Jumbo Frame Support | Yes |
| Product Description | HPE Aruba 5406R 16-port SFP+ (No PSU) v3 zl2 - switch - 16 ports - Managed - rack-mountable |
| Manufacturer Warranty | Limited lifetime warranty |
| MAC Address Table Size | 64K entries |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SMON, CLI, XRMON |
HPE Aruba 5406R 16-port SFP+ (No PSU) v3 zl2 - Switch - Managed - 16 x 1 Gigabit / 10 Gigabit SFP+ - rack-mountable
