Sophos Dual Rate 10GBase-LR 10GbE Fiber Transceiver (Gbic) Single-Mode For All Devices With Sfp/Sfp+ Ports ITFZTCHLR
SKU
425965
Brand
MPN
ITFZTCHLR
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$986.00
Buy Now And Earn 986 Reward Points!
Sophos Dual Rate 10GBase-LR 10GbE Fiber Transceiver (GBIC) Single-Mode for all devices with SFP/SFP+ ports
| SKU | ITFZTCHLR |
|---|---|
| UPC | 821455728963 |
| Brand | Sophos |
| Model | ITFZTCHLR |
| Notes | Module is EEPROM-programmed and uniquely serialized for Sophos compatibility and is stated to be compatible with a broad set of MSA-compliant OEM platforms. |
| DDM/DOM | Supported |
| Warranty | Limited lifetime |
| Connector | Duplex LC / UPC |
| Interface | SFP+ (10 Gigabit Ethernet) |
| Compliance | TAA compliant CE RoHS FDA/IEC60825-1 Class 1 Laser SFP+ / MSA compliant (SFF-8431 / SFF-8432) |
| Dispersion | 70 – 100 ps/nm |
| Media Type | Single-Mode Fiber (SMF) |
| Description | Compatible SFP+ transceiver pre-configured for Sophos platforms. Provides 10GBase-LR throughput up to 10 km over single-mode fiber (SMF) using a 1310 nm DFB laser with a duplex LC/UPC connector. Supports digital diagnostics (DDM/DOM), dual-rate operation for Gigabit and 10G Ethernet, and is compliant with SFP+/MSA electrical and optical specifications. Rated for standard operating temperatures (0 to 70 °C) and shipped with unique serialization and EEPROM programming for OEM compatibility. Common applications include ISP backbone/aggregation, mobile core/backhaul and data center interconnects. |
| Fiber Count | Duplex |
| Form Factor | SFP+ |
| Applications | ISP fiber aggregation and backbone Mobile operator core networks and mobile backhaul Data center interconnections |
| Manufacturer | Sophos |
| Power Supply | +3.3 V |
| Product Title | Sophos ITFZTCHLR Compatible 10GBase-LR SFP+ Transceiver (1310nm, 10 km, LC, DOM, SMF) |
| RX Wavelength | 1310 nm |
| Receiver Type | PIN photodiode |
| TX Wavelength | 1310 nm |
| Maximum Distance | 10 km |
| Transceiver Type | 10GBase-LR (LR / LX) |
| Transmitter Type | DFB Laser |
| Receiver Overload | 0 dBm |
| Temperature Range | 0 to 70 °C |
| What's In The Box | 1 x SFP+ transceiver |
| Supported Data Rate | 1.25 – 10.31 Gbps (dual-rate; supports Gigabit and 10G applications) |
| Receiver Sensitivity | -14.5 dBm |
| Alternate Part Numbers | ITFZTCHLR-AX |
| Guaranteed Link Budget | 6 dB |
| Maximum Transmitting Power | 0.5 dBm |
| Minimum Transmitting Power | -8.2 dBm |
| Supported Protocols / Standards | 10GBase-LR 10 Gigabit Ethernet Gigabit Ethernet STM-64 SFP MSA SFF-8431 SFF-8432 IEC 60825-1 (Class 1 Laser) |
| Wavelength Range (Tx/Rx Bandwidth) | 1260 – 1360 nm |
Sophos Dual Rate 10GBase-LR 10GbE Fiber Transceiver (GBIC) Single-Mode for all devices with SFP/SFP+ ports
