Sophos 1000Base-LX Fiber Transceiver (Gbic) Single-mode - For All Devices With Sfp Ports Itfztchlx
SKU
428610
Brand
MPN
ITFZTCHLX
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$556.00
Buy Now And Earn 556 Reward Points!
1000Base-LX Fiber Transceiver (GBIC) Single-mode - for UTM/SG/XG SFP ports.
| SKU | ITFZTCHLX |
|---|---|
| ECCN | 5A991 (reported) |
| Brand | Sophos (OEM); compatible/third-party versions sold by Axiom, Keystron and others |
| Model | ITFZTCHLX |
| Warranty | Limited lifetime (vendor-dependent) |
| Connector | Duplex LC (LC/UPC) |
| Datasheet | https://www.prolabs.com/Datasheets/ITFZTCHLX-C_datasheets_EN.pdf |
| Wavelength | 1310 nm |
| Description | 1.25Gbps-capable 1000BASE-LX SFP transceiver compatible with Sophos ITFZTCHLX. Operates over single-mode fiber (SMF) with a duplex LC connector at 1310 nm for links up to 10 km. Supports Digital Optical Monitoring (DOM/DDM), uses a FP laser transmitter and PIN photodiode receiver, and runs from a +3.3V supply. Designed to meet SFP MSA and IEEE 802.3z standards; CE/RoHS and laser safety class certifications reported. Limited lifetime warranty (vendor-dependent). |
| Form Factor | SFP (1G) |
| Power Supply | +3.3 V |
| Product Title | Sophos ITFZTCHLX Compatible 1000BASE-LX SFP (1310nm, 10km, LC, DOM) |
| Receiver Type | PIN photodiode |
| TAA Compliant | Reported by some vendors (vendor-dependent) |
| Transceiver Type | 1000BASE-LX (LX) |
| Transmitter Type | FP laser |
| Country Of Origin | USA / UK (reported) |
| Temperature Range | 0 °C to 70 °C |
| Fiber Type / Media | Single-Mode Fiber (SMF), duplex |
| Supported Data Rate | 1.063–1.25 Gbps (nominal 1 G / 1000BASE-LX) |
| Included Accessories | 1x SFP transceiver; documentation |
| Standards & Compliance | SFP MSA (SFF-8477 / SFF-8472 DOM) IEEE 802.3z (1000BASE-LX) CE RoHS Class 1 laser safety (FDA / IEC60825-1) |
| Applications / Protocols | Gigabit Ethernet (1000BASE-LX), 1G Fibre Channel (1.0625 Gbps) |
| Maximum Distance / Reach | 10 km |
| Manufacturer Part Numbers | ITFZTCHLX ITFZTCHLX-AX (Axiom variant) ITFZTCHLX-KS (Keystron variant) |
| Compatible With OEM Part Number(s) | ITFZTCHLX (Sophos) |
| Digital Diagnostic Monitoring (DOM/DDM) | Supported |
| Typical Optical Characteristics (vendor-reported) | Dispersion: 70–100 ps/nm Receiver Overload: -3 dBm Receiver Sensitivity: -22 dBm Maximum Transmit Power: 3 dBm Minimum Transmit Power: -9 dBm Tx/Rx Wavelength Bandwidth: 1260–1360 nm |
Sophos 1000Base-LX Fiber Transceiver (GBIC) Single-mode - for all devices with SFP ports
