Aruba 6300M 24G CL4 Poe 4 SFP56 Switch JL662A
SKU
443120
Brand
MPN
JL662A
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$10,927.00
Buy Now And Earn 10927 Reward Points!
HPE Aruba 6300M - Switch - L3 - Managed - 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit / 25 Gigabit / 50 Gigabit SFP56 (uplink / stacking) - front and side to back - rack-mountable - PoE+ (720 W)
| Product Description | HPE Aruba 6300M - switch - 24 ports - Managed - rack-mountable |
| Device Type | Switch - 24 ports - L3 - Managed - stackable |
| Enclosure Type | Front and side to back rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit / 25 Gigabit / 50 Gigabit SFP56 (uplink / stacking) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 720 W |
| Performance | Switching capacity: 448 Gbps ? Throughput: 334 Mpps ? Latency (1 Gbps): 2.28 ?s ? Latency (10 Gbps): 1.46 ?s ? Latency (25 Gbps): 1.9 ?s ? Latency (50 Gbps): 3.49 ?s ? Stacking bandwidth: 200 Gbps |
| Capacity | Switched virtual interfaces (SVIs): 1000 ? IPv4 host table capacity: 32000 ? IPv6 host table capacity: 32000 ? IPv4 routes (Unicast): 64000 ? IPv6 routes (Unicast): 32000 ? IPv4 routes (Multicast): 8000 ? IPv6 routes (Multicast): 8000 ? IGMP groups: 8000 ? MLD groups: 4000 ? IPv4 ACL entries (ingress): 5000 ? IPv6 ACL entries (ingress): 1250 ? MAC ACL entries (ingress): 5000 ? IPv4 ACL entries (egress): 2000 ? IPv6 ACL entries (egress): 500 ? MAC ACL entries (egress): 2000 |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 9198 bytes |
| Routing Protocol | EGP, BGP-4, IGMPv2, IGMP, VRRP, OSPFv2, IGMPv3, OSPFv3, MSDP, static IPv6 routing, ECMP, MLD, Bidirectional Forwarding Detection (BFD) |
| Remote Management Protocol | RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, SSH, CLI, XRMON, SFTP |
| Features | DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, High Availability, PVST, MSTP support, ACL support, QoS, Jumbo Frames support, MLD snooping, UDLD, Rapid PVST+, DWRR, LLDP support, MIB, DHCP protection, dual firmware images, MVRP, packet storm protection, CoS, SP, broadcast storm protection, ToS, BPDU, VXLAN, Multicast Storm Protection, NTP, RA guard, ZTP, PIM, VLAN Tagging, Rapid Reconfiguration of Spanning Tree (RSTP), IPv4 and IPv6 dual stack, IP multicast, Aruba VSF, dynamic IPv6 lockdown, ND snooping, Unicast Storm protection, Microsoft NLB |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1v, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3bt |
| Dimensions (WxDxH) | 44.2 cm x 38.5 cm x 4.4 cm |
| Weight | 5.55 kg |
| Manufacturer Warranty | Limited lifetime warranty |
HPE Aruba 6300M - Switch - L3 - Managed - 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit / 25 Gigabit / 50 Gigabit SFP56 (uplink / stacking) - front and side to back - rack-mountable - PoE+ (720 W)
