16GB DDR4-3200MHz Non-ECC CL22 Dimm 1Rx8 KVR32N22S8/16
SKU
302097
Brand
MPN
KVR32N22S8/16
Warranty
Standard Manufacturer's Warranty
$543.00
Buy Now And Earn 543 Reward Points!
This document describes ValueRAM's KVR32N22S8/16 is a 2G x
64-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8,
memory module, based on eight 2G x 8-bit FBGA components. The
SPD is programmed to JEDEC standard latency DDR4-3200 timing of
22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
64-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8,
memory module, based on eight 2G x 8-bit FBGA components. The
SPD is programmed to JEDEC standard latency DDR4-3200 timing of
22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
| Product Type | RAM Module |
| CAS Latency | CL22 |
| Number of Pins | 288-pin |
| Form Factor | DIMM |
| Memory Speed | 3200 MHz |
| Memory Size | 16 GB |
| Brand Name | Kingston |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Product Family | ValueRAM |
| Memory Voltage | 1.20 V |
| Manufacturer Part Number | KVR32N22S8/16 |
| Manufacturer Website Address | http://www.kingston.com |
| Packaged Quantity | 1 Each |
| Manufacturer | Kingston Technology Company |
| Product Name | 16GB 1Rx8 2G x 64-Bit PC4-3200 CL22 288-Pin DIMM |
| Product Line | ValueRAM |
| Environmentally Friendly | Yes |
| Length | 133.3 mm |
| Width | 31.2 mm |
| Memory Rank | Single-rank |
| Shipping Dimensions | Height 0.8, Width 4.2, Length 15, Shipping Weight 0.03 KG |
16GB DDR4-3200MHz Non-ECC CL22 DIMM 1Rx8
