The Mean Well MDR-60-24 is a compact and efficient 60W, 24VDC, 2.5A DIN rail power supply, ideal for industrial control systems, automation equipment, and other applications requiring a stable 24V power source. Its slim plastic housing design saves valuable space on the DIN rail while providing enhanced insulation. This reliable power supply features comprehensive protection against short circuits, overload, and overvoltage, ensuring the safety and longevity of your connected devices. With a wide universal AC input range, it's suitable for use in various regions. Enjoy easy installation on TS-35/7.5 or TS-35/15 DIN rails and clear LED indication for power status.

Features
60W, 24VDC, 2.5A output
Ultra-slim plastic case for space-saving installation
Universal AC input range (85~264VAC)
Protections: Short circuit, overload, overvoltage
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or TS-35/15
LED indicator for power-on
DC OK relay contact for remote monitoring
Low no-load power consumption <0.75W
100% full load burn-in test
Specifications
Output Voltage: 24VDC (Adjustable range: 24~30VDC)
Output Current: 2.5A
Output Power: 60W
Input Voltage: 85~264VAC / 120~370VDC
Input Current: 1.0A at 230VAC
Inrush Current: 60A at 230VAC
Efficiency: 88%
Over Voltage Protection: 31.2~36.0VDC, re-power to recover
Overload Protection: 105~150% rated output, recovers once fault removed
Working Temperature: -20~+70°C (refer to datasheet for derating)
Working Humidity: 20~90% RH non-condensing
Dimensions: 40mm x 90mm x 100mm (W x H x D)
Weight: 0.33kg
DIN Rail: TS-35/7.5 or TS-35/15
MTBF: 299.2K hours minimum
Warranty

3-Year Limited Warranty
