Tenda (MX12 1-pack)AX3000 Whole Home Mesh Wi-Fi 6 System, 1pack MX12(1-pack)
SKU
393637
Brand
MPN
MX12(1-pack)
Warranty
Standard Manufacturer's Warranty
$157.00
Buy Now And Earn 157 Reward Points!
Tenda nova MX12 AX3000 Whole Home Mesh Wi-Fi 6 System, 1pack
| SKU | MX12(1-pack) |
|---|---|
| UPC | 705353248184 |
| Bands | Dual‑band (2.4 GHz and 5 GHz) |
| Brand | Tenda |
| Color | berry |
| Model | MX12 |
| Notes | Some listings reference multi‑pack (3‑pack) variants of the MX12; this record reflects specifications and coverage for the 1‑pack variant where specified. |
| Power | Input: AC 100–240V, 50/60Hz Output: DC 12V 1.5A |
| Series | Nova |
| Antenna | Gain: 3 dBi (per antenna, manufacturer spec) Type: Internal Count: 4 |
| Hardware | CPU: Quad‑core Broadcom Buttons: [ "Reset", "Mesh" ] Memory (RAM): 256 MB CPU Frequency: 1.7 GHz LED Indicator: Tri‑color (Green/Yellow/Red) |
| Physical | Dimensions: 86 x 86 x 190 mm (3.39 x 3.39 x 7.48 in) Item Weight: 14.8 ounces |
| Security | WPA3‑SAE WPA2‑PSK |
| Description | Tenda Nova MX12 is an AX3000 dual‑band Wi‑Fi 6 mesh node for whole‑home coverage (1‑pack). Powered by a 1.7 GHz quad‑core processor and 256 MB RAM, the MX12 delivers combined AX3000 throughput (574 Mbps @2.4 GHz + 2402 Mbps @5 GHz) with 160 MHz channel support. Each node includes 3 Gigabit RJ45 ports (one configurable as WAN), supports MU‑MIMO, OFDMA, beamforming, 1024‑QAM and WPA3 security, and integrates with the Tenda Wi‑Fi app for easy setup, mesh expansion, parental controls, guest network and remote management. Designed for mesh networking (Wi‑Fi EasyMesh) with seamless roaming (802.11k/v), the MX12 is suitable for home use and includes power adapter, RJ45 Ethernet cable and quick start guide. |
| Speed Rating | AX3000 |
| Product Title | Tenda Nova MX12 AX3000 Wi‑Fi 6 Mesh Node (1‑Pack) |
| WiFi Standard | 802.11ax (Wi‑Fi 6); backward compatible with 802.11a/b/g/n/ac |
| Certifications | CE FCC RoHS |
| Mesh & Roaming | Roaming: 802.11k/v Mesh Button: Yes (push to add node) Mesh Standard: Wi‑Fi EasyMesh |
| Package Quantity | 1 |
| Special Features | Alexa compatible WPS Parental controls Guest Network Ethernet backhaul IPv6 IPTV support |
| Channel Bandwidth | 160 MHz |
| Wireless Features | MU‑MIMO OFDMA Beamforming AP Steering Band Steering 1024‑QAM |
| Maximum Data Rates | 5GHz: 2402 Mbps (802.11ax) 2.4GHz: 574 Mbps (802.11ax) Combined: Up to 2976 Mbps (AX3000) |
| Coverage (1‑pack) | Up to 2,800 sq. ft. (manufacturer 1‑pack specification) |
| Ethernet Interfaces | WAN/LAN: 1 port configurable as WAN/LAN (reassignable) Ports per node: 3 x 10/100/1000 Mbps RJ45 |
| Included Components | MX12 x 1 Power adapter x 1 Quick start guide x 1 RJ45 Gigabit Ethernet cable x 1 |
| Supported Protocols | IEEE 802.11a/b/g/n/ac/ax IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Regulatory RF Limits | CE: { "5 GHz": "<23 dBm", "2.4 GHz": "<20 dBm" } FCC: { "5 GHz": "<30 dBm", "2.4 GHz": "<30 dBm" } |
| Operating Environment | Humidity: 10% to 90% RH non‑condensing Temperature: 0 °C to 40 °C |
| Software & Management | App: Tenda Wi‑Fi App (iOS and Android) VPN: PPTP server, PPTP/L2TP client Other: DHCP server, Port forwarding, DMZ, UPnP, Firmware upgrade online Web GUI: Supported Operating Modes: [ "Router mode", "AP mode" ] |
| Compatibility (Devices) | Personal computer Gaming console Security camera Printer |
| Manufacturer Part Number | MX12(1-pack) |
| Recommended Maximum Devices | 160+ devices (manufacturer claim) |
