Shure (MXA320B) Table Microph One Array With Intellimix Dsp,Black MXA320B
SKU
443189
Brand
MPN
MXA320B
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,939.00
Buy Now And Earn 1939 Reward Points!
The MXA320 is the next evolution of Shure’s table array microphone that provides high quality audio capture and flexible configuration for AV conferencing environments including boardrooms, huddle rooms and conferencing rooms. It features Steerable Coverage™ Technology with onboard IntelliMix® DSP, streamlined deployment with Designer System Configuration Software and intuitive remote management via ShureCloud, all housed in a familiar, compact, low-profile design.
Product comes with 2 years manufacturing warranty
Product comes with 2 years manufacturing warranty
| Polar Pattern | All channels independently adjustable Cardioid, hypercardioid, supercardioid, toroid, omnidirectional, bidirectional |
| Connector Type | RJ45 |
| Cable Requirements | Cat 5e or higher (shielded cable recommended) |
| Power Requirements | Power over Ethernet (PoE), Class 0 |
| Power Consumption | 5 W maximum |
| Control Software | Shure Designer or web application |
| Operating Temperature Range | −6.7°C (20°F) to 40°C (104°F) |
| Storage Temperature Range | −29°C (−20°F) to 74°C (165°F) |
| Microphone Elements | 4 EMC |
| Frequency Response | 100 Hz to 20 kHz |
| AES67 or Dante Digital Output | Channel Count 6 total channels: 4 direct outputs, 1 automix output, and 1 AEC reference input Sampling Rate 48 kHz Bit Depth 24 |
| Sensitivity | at 1 kHz, −15 dB gain setting −21 dBFS/Pa |
| Maximum SPL | 1 kHz at 1% THD, −15 dB gain setting 115.2 dB SPL |
| Latency | 1.7 ms |
| Built-in Digital Signal Processing | Equalizer (4-band parametric), acoustic echo cancellation (AEC), automatic gain control (AGC), noise reduction, compressor, delay, mute, gain |
| Acoustic Echo Cancellation Tail Length | Up to 250 ms |
The MXA320 is the next evolution of Shure’s table array microphone that provides high quality audio capture and flexible configuration for AV conferencing environments including boardrooms, huddle rooms and conferencing rooms. It features Steerable Coverage™ Technology with onboard IntelliMix® DSP, streamlined deployment with Designer System Configuration Software and intuitive remote management via ShureCloud, all housed in a familiar, compact, low-profile design.
