CnMatrix Ex2052R-P, Intelligent Ethernet PoE Switch, 48 1G And 4 Sfp+, No Crps - No Pwr Cord MXEX2052GxPA10
SKU
391647
Brand
MPN
MXEX2052GxPA10
Warranty
Standard Manufacturer's Warranty
$3,172.00
Buy Now And Earn 3172 Reward Points!
cnMatrix EX2052R-P, Intelligent Ethernet PoE Switch, 48 1G and 4 SFP+, No CRPS - no pwr cord
| PoE | Voltage: 54 V Standard: IEEE 802.3af / IEEE 802.3at Supported: true Power per Port: 30 W |
|---|---|
| SKU | MXEX2052GxPA10 |
| UPC | 5704174864776 |
| MTBF | 202977 hours |
| Brand | Cambium Networks |
| Model | EX2052R-P |
| Ports | SFP+: 4 RJ-45 (10/100/1000): 48 |
| Warranty | 3 Year(s) |
| Management | Switch Management: cnMaestro or XMS (cloud or on‑premise) CLI/Protocol Support: |
| Throughput | 176 Gbit/s |
| Description | 48-port managed Gigabit PoE switch (EX2052R-P) from Cambium Networks' cnMatrix series. Provides 48 × 10/100/1000 RJ‑45 ports with PoE (up to 30 W per port, 54 V) and 4 × SFP+ uplink slots (10 Gbps). Non-blocking, line-rate L2/L3 switching with 176 Gbit/s switching capacity and 120 Mpps forwarding. Features cloud or on‑premise management via cnMaestro/XMS, zero‑touch deployment, policy‑based automation, device profiling and segmentation, QoS, multicast support and advanced security features. 1U rackmount design, 2 fans, LED indicators for Activity/Link/PoE. Removable power supply not included; no power cord included. 3 year warranty. |
| Form Factor | 1U rackmount |
| Performance | Memory Type: DDR-SDRAM Built-in Processor: true |
| Switch Type | Managed |
| Jumbo Frames | Max Size: 9000 Supported: true |
| Power Source | AC |
| Product Title | Cambium Networks cnMatrix EX2052R-P — 48-Port Gigabit PoE Managed Switch with 4× SFP+ Uplinks |
| Uplink Details | 4 × SFP+ (supports 10 Gbps) |
| Forwarding Rate | 120 Mpps (64-byte packets) |
| VLANs Supported | 4000 |
| Additional Notes | Non-blocking, line-rate architecture Fully featured L2/L3 switching |
| MAC Address Table | 16000 |
| Security Features | BPDU filtering/protection DHCP client/relay/snooping IGMP proxy IGMP snooping Password protection SSH/SSL support |
| Memory & Processor | Flash Memory: 128 MB Processor Frequency: 800 MHz Internal Memory (RAM): 512 MB DDR-SDRAM |
| Power Supply Notes | Removable power supply not included; no power cord included |
| Networking & Features | L2/L3 switching Policy-based routing Quality of Service (QoS) Multicast support Broadcast storm control Auto MDI/MDI-X Zero-touch deployment Policy Based Automation Device profiling and segmentation Cloud/on‑premise management (cnMaestro / XMS) |
| Physical Specifications | Color: Black Net Weight: 4.3 kg Reset Button: true Product Depth: 35 cm Product Width: 44 cm LED Indicators: [ "Activity", "Link", "PoE" ] Number of Fans: 2 Product Height: 4.4 cm Gross Weight (package): 5 kg |
| Manufacturer Part Number | MXEX2052GXPA10 |
cnMatrix EX2052R-P, Intelligent Ethernet PoE Switch, 48 1G and 4 SFP+, No CRPS - no pwr cord
