Shure (MXWAPXD2)MXW NEXT2 All-In-One Access Point Transceiver W/Mic Charger+Intellimix Dsp MXWAPXD2AZ=-Z11
SKU
439768
Brand
MPN
MXWAPXD2AZ=-Z11
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,896.00
Buy Now And Earn 1896 Reward Points!
The Shure MXWAPXD2 is a 2-channel Access Point Transceiver for the Microflex Wireless neXt 2 system, acting as the central hub for hybrid meetings, classrooms, and presentations, combining wireless microphone management, charging, audio processing (IntelliMix DSP), and connectivity (Analog, Dante, USB-C) in one discreet unit, allowing seamless audio for both in-person and remote participants.
| Working Range | 45 m (150 ft) Outdoor and line-of-sight between user and MXWAPX. Actual range depends on RF power setting, signal absorption, reflections, and interference. |
| Audio Frequency Response | 30 Hz ‒ 19 kHz (+0.5dB/3dB) Dependent on microphone type and audio output. Microphone transducers not included in measurement. MXWAPX set to Direct Mode. |
| Digital Audio Processing | 24 bit / 48 kHz |
| Digital Audio Networking | Dante, AES67 |
| Security | AES-256 Encryption Dante and DECT over-the-air |
| Latency | 18 ms (nominal) MXW1/2/6/8X microphone input to MXWAPX output. MXWAPX set to SD RF density mode. Latency depends on output port and RF density mode. |
| System Audio Polarity | Positive pressure on MXW1X/2X/6X/8X microphone diaphragm produces positive voltage on + pin (with respect to - pin) of MXWAPX analog output and a positive digital signal on the MXWAPX USB and Dante outputs. |
| Radio Transmission | Time Division Multiple Access (TDMA), Gaussian Frequency Shift Keying (GFSK), 365 kHz max. deviation |
| DECT RF Sensitivity | < -90 dBm |
| DECT RF Transmission Power | RF Power: Low 2 dBm; 2 mW RF Power: Medium 9 dBm; 8 mW RF Power: High 16 dBm (Egypt: 12 dBm); 40 mW (Egypt: 16 dBm) RF Power: Maximum 21 dBm (Egypt: 15 dBm); 125 mW (Egypt: 32 mW) |
| Cable Requirements | Cat 5e or higher, shielded, 100 m maximum between network devices |
| Network Addressing Capability | DHCP, link-local, static |
| Operating Temperature Range | 5℃ (41℉) - 40℃ (104℉) |
| Operating Humidity | RH < 95% |
| Storage Temperature Range | -20℃ (-4℉) to 60℃ (140℉) |
| Analog Input | Line Level Input +28 dBV Aux Level Input +15 dBV |
| Analog Outputs | Line Level Output +17 dBV Aux Level Output +6 dBV Mic Level Output -13 dBV |
| Power Requirement | 4.5V ‒ 5.5V, 2500 mA (via USB-C) |
| Network Interface | Dual ‒ RJ45: Gigabit Ethernet, Dante digital audio |
| Docking Interface | 5 V / 0.5 A |
The Shure MXWAPXD2 is a 2-channel Access Point Transceiver for the Microflex Wireless neXt 2 system, acting as the central hub for hybrid meetings, classrooms, and presentations, combining wireless microphone management, charging, audio processing (IntelliMix DSP), and connectivity (Analog, Dante, USB-C) in one discreet unit, allowing seamless audio for both in-person and remote participants.
