CyberPower Switched Mbo EPDU PDU81004 1RU Horizontal 12Amp Input - Snmp Network Connection - 8x Iec-320 C13 Out -Iec-320 C14 In - 2 Yrs Adv. Replacement Wty PDU81004
SKU
408021
Brand
MPN
PDU81004
Warranty
Standard Manufacturer's Warranty
$727.00
Buy Now And Earn 727 Reward Points!
GENERAL
Type: Switched Metered-by-Outlet
Phase: Single Phase
INPUT
Nominal Input Voltage ( Vac ): 100 ~ 240
Input Frequency ( Hz ): 50 / 60
Maximum Input Current ( A ):
12 (UL)
10 (CE)
Input Connector Type: IEC C14 x 1
Power Cord Length (m.): 3.05
OUTPUT
Output Voltage ( V ): Depends on Input
Outlets - # of Bank(s) ( Bank ): 1
Outlet(s) - Total: 8
Outlet(s) - Front: 8
Outlet Type:
IEC C13 x 8
Remote Individual Outlet Control: Yes
PHYSICAL
Installed Rack Height (U): 1
Form Factor: 1U Vertical Rackmount , 1U Horizontal Rackmount
Enclosure Construction: Steel
Color: Black
Cord Retention Tray: Yes
IEC Receptacle Locking: Yes
External Site Ground Pin: Yes
Adjustable Mounting Brackets: 2 Set (L-short, L-long)
PHYSICAL SIZE
Dimensions (WxHxD) (mm.): 433 x 44 x 112
Weight (kg.): 2.1
SHIPPING DIMENSIONS
Dimensions (WxHxD) (mm.): 500 x 65 x 250
Weight (kg.): 3.9
Type: Switched Metered-by-Outlet
Phase: Single Phase
INPUT
Nominal Input Voltage ( Vac ): 100 ~ 240
Input Frequency ( Hz ): 50 / 60
Maximum Input Current ( A ):
12 (UL)
10 (CE)
Input Connector Type: IEC C14 x 1
Power Cord Length (m.): 3.05
OUTPUT
Output Voltage ( V ): Depends on Input
Outlets - # of Bank(s) ( Bank ): 1
Outlet(s) - Total: 8
Outlet(s) - Front: 8
Outlet Type:
IEC C13 x 8
Remote Individual Outlet Control: Yes
PHYSICAL
Installed Rack Height (U): 1
Form Factor: 1U Vertical Rackmount , 1U Horizontal Rackmount
Enclosure Construction: Steel
Color: Black
Cord Retention Tray: Yes
IEC Receptacle Locking: Yes
External Site Ground Pin: Yes
Adjustable Mounting Brackets: 2 Set (L-short, L-long)
PHYSICAL SIZE
Dimensions (WxHxD) (mm.): 433 x 44 x 112
Weight (kg.): 2.1
SHIPPING DIMENSIONS
Dimensions (WxHxD) (mm.): 500 x 65 x 250
Weight (kg.): 3.9
| LCD | Color: Yes Rotatable: Yes Hot-swappable: Yes Displayed Info: [ "Input Voltage (V)", "Input Frequency (Hz)", "Current (A)", "Power Consumption (W)", "Network Information", "Serial Number", "Environment Status", "Hardware/Firmware Version" ] |
|---|---|
| SKU | PDU81004 |
| UPC | 0649532616244 |
| Type | Switched Metered-by-Outlet PDU |
| Brand | CyberPower |
| Color | Black |
| Model | PDU81004 |
| Notes | Per-source consolidated specification. Values presented only reflect provided product information; no external inference was made. |
| Weight | 4.6 lbs (2.1 kg) |
| Category | Power and Rack Equipment |
| Features | Per-outlet power metering and monitoring Local and remote outlet switching and sequencing Automatic event notifications (email, SMS, SNMP traps) Cord retention tray IEC receptacle locking Adjustable mounting brackets (short and long) User-upgradeable firmware PowerPanel management software compatibility Switch-free design option to prevent accidental shutdown Ultra-low idle power consumption |
| Warranty | 3-year limited warranty |
| Rack Units | 1U |
| Cord Length | 10 ft (3.05 m) |
| Description | The CyberPower PDU81004 is a 1U rack-mount switched, metered-by-outlet power distribution unit designed for data centers and network closets. It provides per-outlet real-time metering and individual outlet switching (local and remote) for remote reboots, scheduled power sequencing and load management. Management features include a color, rotatable LCD (hot-swappable), built-in web interface, daisy-chain capability, RJ45/serial/USB connectivity, environmental sensor support and automatic notifications via email, SMS or SNMP. The PDU includes a 10 ft (3.05 m) power cord, cord retention tray, adjustable mounting brackets and a three-year limited warranty. |
| Form Factor | 1U rackmount (horizontal or vertical) |
| Outlet Type | IEC C13 |
| Outlet Count | 8 |
| Sub-Category | Power Equipment |
| Input Current | 15 A maximum (derated to 12 A UL / 10 A CE); rated input current: 12 A (UL) / 10 A (CE) |
| Input Voltage | AC 100 - 240 V |
| Product Title | CyberPower PDU81004 1U Switched Metered-by-Outlet PDU — 8x IEC C13, IEC C14 Input, 100-240V, 10 ft Cord |
| Authentication | RADIUS LDAP LDAPS Windows AD |
| Certifications | CE FCC Class A UL 62368 EN 55032 Class A EN 55035 IEC 62368 RoHS compliant |
| Input Connector | IEC 60320 C14 (x1) |
| Input Frequency | 50 / 60 Hz |
| Monitoring Level | Metered-by-Outlet |
| Metering Accuracy | ±1% |
| Output Connectors | IEC 60320 C13 (x8) |
| Dimensions (WxHxD) | 17.05 x 1.75 x 4.41 in (433 x 44 x 112 mm) |
| Enclosure Material | Steel (industrial-grade metal housing) |
| Operating Elevation | 0 to 3,500 m (0 to 11,483 ft) |
| Storage Temperature | -15 to 65 °C (5 to 149 °F) |
| Supported Protocols | IPv4/v6 SNMP v1/v3 HTTP/HTTPS TCP/IP UDP DHCP NTP DNS SMTP SSH SSL/TLS Telnet FTP Syslog |
| Included Accessories | PDU unit Power cord (10 ft / 3.05 m) Cord retention tray Adjustable mounting brackets (short & long) Screw kit (M4, M5, M3 as supplied) Cable ties RJ45/DB9 serial cable User manual Product registration/software download card |
| Management Interfaces | Ethernet (RJ45) Serial (RJ45/DB9 compatible) USB Type-A (for firmware upgrade) Environmental sensor RJ45 Daisy-chain RJ45 (in/out) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Idle Power Consumption | < 5 W |
| Daisy Chain / Cascading | Yes (monitor/control multiple PDUs under one IP) |
| Storage Relative Humidity | 0 to 95% non-condensing |
| Operating Relative Humidity | 0 to 95% non-condensing |
| Environmental Sensor Supported | Yes |
| Remote Individual Outlet Control | Yes |
CyberPower Switched MBO ePDU PDU81004 1RU horizontal 12Amp input - SNMP Network Connection - 8x IEC-320 C13 out -IEC-320 C14 in - 2 Yrs Adv. Replacement WTY
