Cambium CnPilot E700 Outdoor (Row) 802.11ac Wave 2, 2x2/4x4, Ap PL-E700X00A-RW
SKU
298048
Brand
MPN
PL-E700X00A-RW
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,185.00
Buy Now And Earn 1185 Reward Points!
Cambium cnPilot e700 Outdoor (ROW) 802.11ac wave 2, 2x2/4x4, AP
| Mesh | Multi-hop mesh; can dedicate radio for mesh backhaul or use both bands for simultaneous client and mesh access |
|---|---|
| Brand | Cambium Networks |
| Model | cnPilot e700 |
| Ports | 2 x Gigabit Ethernet (10/100/1000Base-T); auxiliary PoE Out port |
| Region | ROW (Rest of World) |
| Antenna | Integrated omni-directional antenna |
| Category | Networking |
| Security | WPA-2 (802.11i) — WPA2-Enterprise (802.1x/EAP) & WPA2-PSK; Open |
| Management | Controller-less roaming; cloud management (cnMaestro) per product information |
| SSID Count | 16 |
| Beamforming | Supported (standards-based beamforming) |
| Description | The Cambium Networks cnPilot e700 is an enterprise-grade outdoor access point delivering high-performance 802.11ac Wave 2 (Wi‑Fi 5) dual-band connectivity with beamforming and an integrated omni antenna. Designed for harsh outdoor environments (IP67), the e700 supports high-density deployments with up to 512 concurrent clients, 16 SSIDs, controller-less roaming, multi-hop mesh, and advanced features such as DFS, dynamic VLANs, ACLs and zero-touch provisioning. It includes dual Gigabit Ethernet ports with an aux PoE Out for wireless backhaul or to power an 802.3af camera; PoE injector is not included. Ruggedized for extreme temperatures (-40°C to +65°C) and packaged with mounting brackets, the e700 is suited for campus, hospitality and public Wi‑Fi applications. |
| Other Notes | No PoE injector included; ROW variant |
| Power / PoE | Supports PoE; PoE injector not included. Aux PoE Out can power wireless backhaul or an 802.3af camera |
| Unit Weight | 1.70 kg (1700 g / 3.174 lbs) |
| Antenna Gain | 8 dBi (integrated) |
| Key Features | IP67 UV-rated rugged enclosure Supports up to 512 concurrent clients and 16 SSIDs DFS channel support Dynamic VLANs and Access Control Lists (ACL) Zero-touch provisioning Dual on-board active/standby firmware banks (failover) Electrical heater for cold-start LTE resilience filtering ESD protection / industrial grade |
| Sub-Category | Wireless Networking |
| Product Title | Cambium Networks cnPilot e700 Outdoor 802.11ac Wave 2 Dual-Band Omni IP67 Access Point (PL-E700X00A-RW) |
| Frequency Range | 2.4 GHz: 2.4–2.4835 GHz (Channels dependent on region); 5 GHz: 5.15–5.85 GHz |
| Shipping Weight | 2.45 kg (seller-specified shipping weight) |
| Wireless Standard | 802.11ac (Wave 2) |
| Dimensions (WxHxD) | 315 x 215 x 66 mm |
| Operating Humidity | 10% to 95% |
| Radio Configuration | Dual-band: 4x4 (5 GHz) / 2x2 (2.4 GHz) |
| Environmental Rating | IP67 |
| Included Accessories | Wall and pole mounting brackets (packaged with unit) |
| Operating Temperature | -40°C to +65°C |
| Max Concurrent Clients | 512 |
| Manufacturer Part Number | PL-E700X00A-RW |
Cambium cnPilot e700 Outdoor (ROW) 802.11ac wave 2, 2x2/4x4, AP
