FEATURE SUMMARY

80 PLUS® Gold certified
Semi-Modular Cables
Compact Size - 140 mm deep
Tight Voltage Regulation
Cable-free Connection Design
S2FC - Smart and Silent Fan Control
DC to DC Converter Design
Multi-GPU setup
Gold plated connectors
7 years warranty

Specifications
Technical Specifications
80PLUS® Gold
Form Factor Intel ATX 12 V
Dimensions 140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control S2FC
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information Modularity Semi-modular
Cable type Webbed cables (attached)
Flat black cables(modular)
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 100,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 7 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 9 - 4.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 20 A 20 A 54 A 0.3 A 3 A
100 W 648 W 3.6 W 15 W
Total continuous power 650 W
Cables
Connector Connector count Cable count Cable
Main Power (24/20 pins) 1 1
CPU (8/4 pins) 1 1
PCIe (8/6 pins) 4 0
2
SATA 6 1
0
0
1
0
0
Peripheral 3 1
0
Floppy 1 0

Specifications are subject to change without prior notice.
