FEATURE SUMMARY
ATX 3.0 and PCIe 5.0 Cable (12VHPWR)
80 PLUS® Gold certified
Compact Size - 140 mm deep
Top-Quality 135 mm FDB Fan
Digital Hybrid Fan Control
S3FC - Fanless until 30% load
Cable-free Connection Design
Tight Voltage Regulation
Gold plated connectors
10 years warranty

Technical Specifications
80PLUS® Gold
Cybenetics Efficiency Level TBA
Cybenetics Noise Level TBA
Form Factor Intel ATX 12V
Dimensions 140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size 135 mm
Fan Control S3FC - Fanless until 30% load
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40°C, 15% - 65% RH
Cable Information Modularity Fully Modular
Cable type Individual Black Cables with Braided Pattern
Electrical Features Operating Temperature 0 - 50°C
MTBF @ 25 °C, excl. fan 100,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 10 Years

Power Output

AC Input
Voltage: 100 V - 240 V

Current: 10 - 5 A

Frequency: 50 Hz - 60 Hz

DC Output
Rail

+3.3 V

+5 V

+12 V

-12 V

+5 VSB

Maximum Power

20 A

20 A

62 A

0.3 A

3 A

100 W

744 W

3.6 W

15 W

Total Continuous Power

750 W
