Qnap QM2 Series Qm2-2P2G2T, 2 X PCIe 2280 M.2 SSD Slots, PCIe Gen3 X 4 , 2 X Intel I225LM 2.5GbE Nbase-T Port QM2-2P2G2T
SKU
369837
Brand
MPN
QM2-2P2G2T
Warranty
Standard Manufacturer's Warranty
$321.00
Buy Now And Earn 321 Reward Points!
The QM2-2P2G2T adds support for M.2 SSDs and 2.5GbE connectivity to your QNAP NAS. Combining M.2 SSD and 2.5GbE connectivity into one solution, the QM2 PCIe expansion card improves overall NAS performance by enabling SSD caching while providing an affordable upgrade path for adopting 2.5GbE networks. As a PCIe card, the QM2-2P2G2T does not occupy any 3.5-inch drive bays, allowing you to upgrade your NAS without impacting your potential storage capacity.
| MPN | QM2-2P2G2T |
|---|---|
| SKU | QM2-2P2G2T |
| UPC | 885022021277 |
| Brand | QNAP |
| Model | QM2-2P2G2T |
| Cooling | Heatsink and smart fan (quiet cooling module) |
| Category | Storage |
| Interface | PCIe |
| M.2 Slots | 2 x M.2 (M key) 2280 |
| Dimensions | Width: 0.8 in / 20.6 mm Height: 2.7 in / 68.9 mm Length: 6.01 in / 152.65 mm |
| PCIe Lanes | x4 |
| Description | The QNAP QM2-2P2G2T is a PCIe expansion card that adds two M.2 2280 NVMe SSD slots and dual 2.5GbE (2.5GBASE-T) RJ45 ports to compatible NAS, PC, and workstation systems. It supports SSD caching to boost IOPS and overall system performance, and includes a quiet cooling module (heatsink + smart fan), M.2 SSD thermal sensors, and LED indicators for drive status. Low-profile mounted by default, the card ships with low-profile flat and full-height brackets; M.2 SSDs are not included. Supported OS: QTS, QuTS hero, Windows 10 (1809 or later), Windows Server 2019, and Linux 4.2/5.x (Windows/Linux require the Intel I225LM driver). |
| Form Factor | Low profile (includes low-profile flat and full-height brackets) |
| PCIe Version | PCIe 3.0 |
| RAID Support | No |
| Sub-Category | Drive Controllers |
| Network Ports | 2 x 2.5GBASE-T RJ45 (dual 2.5GbE) |
| Product Title | QNAP QM2-2P2G2T Dual M.2 2280 NVMe PCIe 3.0 x4 Card with Dual 2.5GbE RJ45 Ports |
| LED Indicators | LED indicators for monitoring M.2 SSD status |
| Package Weight | 0.67 lb |
| OS Compatibility | QTS QuTS hero Windows 10 (1809 or later) Windows Server 2019 Linux 4.2 Linux 5.x |
| System Connection | PCI Express 3.0 x4 (PCIe Gen3, x4) |
| Thermal Monitoring | M.2 SSD thermal sensors |
| Driver Requirements | Intel I225LM driver required for Windows and Linux |
| External Interfaces | 2 x RJ45 |
| Included Accessories | Low-profile bracket (mounted by default), low-profile flat bracket, full-height bracket |
| Supported Drive Type | M.2 SSD (NVMe) |
| Box Dimensions (LxWxH) | 7.7 x 4.8 x 2.1 in |
| Use Cases / Key Features | Adds support for two M.2 2280 NVMe SSDs for cache/expanded storage capacity Dual 2.5GbE ports for higher network throughput Improves IOPS and application performance (SSD caching) Does not occupy 3.5-inch drive bays |
| Compatible Products / Systems | Select QNAP NAS models (examples listed by vendor): QVP-63 TS-453 TS-473 TS-673 TS-832 TS-873 TVS-672 TVS-872 h1288 VioStor QVP-85 |
| Network Backward Compatibility | Compatible with 1GbE, 100MbE and 10MbE |
QNAP QM2 series QM2-2P2G2T, 2 x PCIe 2280 M.2 SSD slots, PCIe Gen3 x 4 , 2 x Intel I225LM 2.5GbE NBASE-T port
