Qnap QMiro-201W-AU,WiFi Mesh Tri-band Home Sd-Wan Router,2 Years Wty QMiro-201W-AU
SKU
365559
Brand
MPN
QMiro-201W-AU
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Special Price $228.00 Regular Price $263.00
Buy Now And Earn 228 Reward Points!
QNAP QMiro-201W-AU,WiFi Mesh Tri-band home SD-WAN router,2 Years WTY
| CPU | Qualcomm IPQ4019, Quad-core ARM Cortex-A7 @ 716.8 MHz |
|---|---|
| SKU | QMiro-201W-AU |
| Mesh | Coverage: One unit: up to 2,100 sq ft / 195 m² (coverage varies with placement and environment) Mesh Handover: Supports Wi‑Fi handover for seamless roaming Mesh Max Units: Up to 4 QMiro units (1 router + 3 satellites) Dedicated Mesh Band: Dedicated 5 GHz band for mesh backhaul |
| Brand | QNAP |
| Model | QMiro-201W-AU |
| Power | Input: 12 V DC Power Consumption: 24 W |
| Design | Morandi blue, fanless near-silent cooling (fanless design) |
| Memory | 512 MB DDR3 |
| Weight | 0.44 kg |
| Antenna | Type: Internal antennas (Wi‑Fi and Bluetooth) Count: 5 internal antennas (4 Wi‑Fi, 1 Bluetooth) Antenna Details: 2 internal dual-band (2.4/5 GHz) antennas; 2 internal single-band (5 GHz) antennas; 1 Bluetooth antenna |
| Buttons | Reset WPS |
| Category | Networking |
| Warranty | 2 Years Limited Warranty |
| Bluetooth | Notes: Bluetooth antenna included Version: Bluetooth 5.0 |
| USB Ports | 1 x USB-A 3.2 Gen1 |
| Dimensions | 68 x 100 x 175.5 mm |
| Description | The QNAP QMiro-201W-AU is a tri-band Wi‑Fi 5 (802.11ac, AC2200) mesh router designed for home and small-office SD‑WAN deployments. It provides a dedicated Mesh 5GHz band for high-bandwidth backhaul and supports Mesh Wi‑Fi handover for seamless roaming. Managed via the web-based QuRouter OS and compatible with QNAP's QuWAN SD‑WAN/Orchestrator, it includes enterprise-grade VPN, parental controls and security features. Hardware highlights: Qualcomm IPQ4019 quad-core CPU, 512MB DDR3, 4GB eMMC, 2x 1GbE LAN ports, USB 3.2 Gen1, Bluetooth 5, fanless design and coverage up to ~195 m² (2100 sq ft) per unit; supports up to 4 QMiro units in a mesh (1 router + up to 3 satellites). |
| Antenna Gain | 5 GHz: 4.9 dBi, 6.0 dBi 2.4 GHz: 4.6 dBi, 2.7 dBi Bluetooth: 2.3 dBi |
| SD-WAN / VPN | Notes: Supports QuWAN Cloud Orchestrator for multi-site VPN and automatic mesh VPN topology Solution: QuWAN (QNAP SD‑WAN) |
| Sub-Category | Routers and Components |
| Flash Storage | 4 MB SPI NOR Flash; 4 GB eMMC |
| Product Title | QNAP QMiro-201W-AU Tri-Band Mesh Wi‑Fi 5 SD‑WAN Router (AC2200) |
| Certifications | JATE CE FCC BSMI NCC IC SRRC VCCI RCM OFCA |
| Ethernet Ports | 2 x 1 GbE (RJ45) |
| Packing Weight | 1.11 kg |
| Wireless Bands | 2.4 GHz 5 GHz Dedicated Mesh 5 GHz backhaul |
| Package Content | QNAP QMiro-201W-AU router Ethernet cable Power cord AC adapter Quick Installation Guide |
| Wireless Standard | 802.11a/b/g/n/ac (Wi‑Fi 5) |
| Operating Humidity | 5% to 95% non-condensing |
| Wireless Bandwidth | 20/40/80 MHz |
| Security & Controls | Zero Trust security model (block connections/devices/IPs via NAT) Parental controls (site block, screen time, keyword filtering) |
| Wireless Generation | Wi‑Fi 5 (802.11ac) |
| Manufacturer Contact | https://www.qnap.com/i/au/ |
| Operating Temperature | 0 °C to +40 °C |
| Wireless Speed Rating | AC2200 |
| Wireless Speeds (per band) | 5 GHz: 867 Mbps + 867 Mbps (two 5GHz radios) 2.4 GHz: 400 Mbps (2x2) |
| Operating System / Management | QuRouter OS: Web-based GUI, at-a-glance dashboard; supports router or AP mode; configure NAT, VPN, security and QuWAN functions |
