Qnap Qsw-308S 8port 1Gbps, 3port Sfp+ Unmanaged Switch QSW-308S
SKU
289611
Brand
MPN
QSW-308S
Warranty
Standard Manufacturer's Warranty
$312.00
Buy Now And Earn 312 Reward Points!
QNAP QSW-308S 8port 1Gbps, 3port SFP+ unmanaged switch
| SKU | QSW-308S |
|---|---|
| Brand | QNAP |
| Color | Reported as Black by some sources; product descriptions also reference a white polished/textured finish |
| Model | QSW-308S |
| Power | Power Supply: External adapter Input Voltage: 100-240 VAC, 50/60 Hz Max Power Consumption: 36 W |
| Weight | Net: 0.74 kg Gross: 1.16 kg |
| Fanless | true |
| Category | Networking |
| Warranty | 2 years (730 days) |
| Description | Compact, fanless unmanaged switch providing hybrid 10GbE and Gigabit connectivity for homes and small offices. The QNAP QSW-308S features three 10GbE SFP+ ports and eight 1GbE RJ45 ports, a 76 Gbps switching capacity, and a silent desktop form factor. SFP+ interfaces support DAC direct-attach copper and 10G-SFP-T copper transceivers for 10GBASE-T/NBASE-T connections over Cat5/6 cabling; note the SFP+ ports are not backward compatible with 1GbE SFP. The unit includes a DC/AC power adapter, power cord, rubber feet, and quick installation guide. |
| Form Factor | Desktop |
| Jumbo Frames | Up to 10K |
| Sub-Category | Switches and Hubs |
| Product Title | QNAP QSW-308S 11-Port Unmanaged 10GbE Switch (3x 10G SFP+ / 8x 1GbE RJ45) |
| Certifications | CE FCC VCCI BSMI RCM CCC |
| LED Indicators | Per-port Speed/Link/Activity; System Power/Status |
| Port Breakdown | 1GbE RJ45: 8 × RJ45 (1GbE) 10GbE SFP+: 3 × SFP+ (10GbE) |
| Management Type | Unmanaged |
| Number of Ports | 11 |
| MAC Address Table | 16K |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (HxWxD) | 42.5 × 290 × 127 mm |
| Switching Capacity | 76 Gbps |
| Compatibility Notes | 10GbE SFP+ ports are not backward compatible with 1GbE SFP modules. SFP+ ports support DAC direct-attach copper and 10G-SFP-T copper transceivers for 10GBASE-T/NBASE-T over Cat5/6/5e cabling. One source reports potential compatibility issues with Intel X520 adapters that may cause ports to alternate between up/down status. |
| Supported Standards | IEEE 802.3 IEEE 802.3u (100BASE-TX) IEEE 802.3ab (1000BASE-T) IEEE 802.3an (10GBASE-T) |
| Included Accessories | Power adapter Power cord Rubber feet Quick Installation Guide (QIG) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Non-Blocking Throughput | 38 Gbps |
| Electromagnetic Compliance | CLASS B, UL62368 |
QNAP QSW-308S 8port 1Gbps, 3port SFP+ unmanaged switch
