Cisco Qsfp 40g Ethernet - Lr4 Lite Lc 2km Wsp-q40glr4l=
Product Overview
The Cisco® 40GBASE QSFP (Quad Small Form-Factor Pluggable) portfolio offers customers a wide variety of high-density and low-power 40 Gigabit Ethernet connectivity options for data center, high-performance computing 00networks, enterprise core and distribution layers, and service provider applications.
Features and Benefits of Cisco QSFP Modules
● Hot-swappable input/output device that plugs into a 40 Gigabit Ethernet Cisco QSFP port
● Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
● Certified and tested on Cisco QSFP 40G ports for superior performance, quality, and reliability
● High-speed electrical interface compliant to the IEEE 802.3ba standard
● QSFP Form factor, 2-wire I2C communication interface and other low-speed electrical interface compliant to SFF 8436 and QSFP Multisource Agreement (MSA)
| Basic | |
|---|---|
| Brand Name: | Cisco |
| Interfaces/Ports Details: | 1 x 40GBase-LR4 |
| Maximum Data Transfer Rate: | 40 |
| Product Type: | QSFP |
| General Information | |
|---|---|
| Brand Name: | Cisco |
| Manufacturer Part Number: | WSP-Q40GLR4L= |
| Manufacturer Website Address: | http://www.cisco.com/c/en_au |
| Manufacturer: | Cisco Systems, Inc |
| Product Model: | WSP-Q40GLR4L |
| Product Name: | 40GBase-LR4L QSFP Module for SMF |
| Product Type: | QSFP |
| Interfaces/Ports | |
|---|---|
| Interfaces/Ports Details: | 1 x 40GBase-LR4 |
| Media & Performance | |
|---|---|
| Fiber Mode Supported: | Single-mode |
| Maximum Data Transfer Rate: | 40 |
| Miscellaneous | |
|---|---|
| Compatibility: | MSA Compliant |
| Physical Characteristics | |
|---|---|
| Depth: | 72.4 mm |
| Form Factor: | Hot-swappable |
| Height: | 13.5 mm |
| Width: | 18.4 mm |
| Technical Information | |
|---|---|
| Application/Usage: | Data Networking |
